Description
The GLC-ZX-SM is a Cisco compatible 1G SFP transceiver module that offers long-distance optical data transmission over single-mode fiber. It supports a data rate of 1.25Gbps and operates at a wavelength of 1550 nm, making it suitable for high-performance networking applications up to 80 kilometers.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
Cisco
|
| Category |
|
| Part Number |
GLC-ZX-SM
|
| Subcatecory |
|
| Compatibility |
Cisco Compatible |
Wavelength
|
1550 nm (Tx/Rx) |
| Wavelength Bandwidth |
1528–1565 nm |
| Data Rate |
1.063–1.25 Gbps
|
| Media Type |
Single-Mode Fiber (SMF)
|
| Connector Type |
Duplex LC
|
| Optical Budget |
24 dB
|
| Max Distance |
80 km
|
| DDM/DOM |
Supported
|
| Temperature Range |
0° to 70°C
|
Information About GLC-ZX-SM
The GLC-ZX-SM is a Small Form-Factor Pluggable (SFP) transceiver module engineered for long-range single-mode fiber (SMF) communications. The module is designed for Cisco systems but also works with a wide range of networking equipment. Operating at a 1550 nm wavelength, it ensures high optical power budget and robust performance over extended distances.
Key Features:
-
Long-Range Connectivity: Supports up to 80 km transmission distance over SMF.
-
Optical Power Budget: Offers a high 24 dB budget, ensuring strong signal quality.
-
Wavelength and Bandwidth: 1550 nm Tx/Rx wavelength with 37 nm bandwidth (1528–1565 nm).
-
DDM/DOM Support: Enables real-time diagnostics for performance monitoring.
-
Data Rate Support: Compatible with 1.063 to 1.25 Gbps for Ethernet and Fibre Channel applications.
-
Reliable Operating Range: Functions within a commercial temperature range of 0° to 70°C.
The GLC-ZX-SM is ideal for high-capacity data links in enterprise and service provider networks.
