This General Electric TH3364SS316 Spec-Setter disconnect switch carries ratings of 200 A, 3-pole, 600 VAC. It provides 200kA@600V interrupting rating.
Factory specification: disconnect, heavy duty safety switches, UL listed, 3PH, 3P, 4 wire, 600V, 200A, 200kA@600V, nema 4/4X stainless steel 316 enclosure, Fusible accepts class R fuses, Single style, suitable for outdoor use, disconnect safety switches.
TH3364SS316 Technical Specifications
| Manufacturer |
General Electric |
| Series |
Spec-Setter |
| Type |
Disconnect Switch |
| Voltage |
600 V |
| Amperage |
200 A |
| Poles |
3 |
| Phase |
3 |
| AIC Rating |
200kA@600V |
| Nema Rating |
4 |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
R |
| Wire |
4 |
The TH3364SS316 is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
