[shortdesc]FG-3500F-BDL-809-36 NGFW, 595 Gbps firewall, 6x 100GE QSFP28, 32x 25GE SFP28, FortiCare Premium + FortiGuard Enterprise Protection (3 Year).[/shortdesc]
[properties]
| Model / SKU |
FG-3500F-BDL-809-36 |
| Bundle / Subscription |
Hardware + FortiCare Premium + FortiGuard Enterprise Protection (3 Year) |
| Form Factor |
Rack Mount, 2 RU |
| Firewall Throughput |
595 Gbps |
| Interfaces |
6x 100 GE QSFP28 / 40 GE QSFP+, 32x 25 GE SFP28 / 10 GE SFP+ / GE SFP, 2x 10 GE / GE RJ45 Management |
| Power Input |
100-240V AC, 50/60 Hz |
[/properties]
[specifications]
| System Performance |
| IPS Throughput |
72 Gbps |
| NGFW Throughput |
65 Gbps |
| Threat Protection Throughput |
63 Gbps |
| IPv4 Firewall Throughput (1518/512/64 byte, UDP) |
595 / 590 / 420 Gbps |
| Firewall Latency |
2.98 µs |
| IPsec VPN Throughput (512 byte) |
165 Gbps |
| SSL-VPN Throughput |
16 Gbps |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
63 Gbps |
| Interfaces and Modules |
| 100 GE QSFP28 / 40 GE QSFP+ Slots |
6 (Hardware Accelerated) |
| 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots |
32 (Hardware Accelerated) |
| 10 GE / GE RJ45 Management Ports |
2 |
| USB Ports (Client / Server) |
1 / 1 |
| Console Port |
1 |
| Power and Environment |
| Power Supply |
Redundant Power Supplies (Hot Swappable), Default dual AC PSU |
| Power Consumption (Average / Maximum) |
760 W / 1174 W |
| AC Current (Maximum) |
12A@120V, 9A@240V |
| AC Power Supply |
100–240V AC, 50/60 Hz |
| Dimensions and Weight |
| Form Factor (supports EIA/non-EIA standards) |
Rack Mount, 2 RU |
| Height x Width x Length (inches) |
3.5 x 17.4 x 21.9 |
| Height x Width x Length (mm) |
89 x 443 x 556 |
| Weight |
43.8 lbs (19.9 kg) |
[/specifications]
[accesories]
| Included Transceivers |
2x SFP+ (SR 10 GE) |
| Optional Accessories |
Rack Mount Sliding Rails (SP-FG3040B-RAIL), AC Power Supply (FG-7040E-PS-AC), Transceiver Modules (FN-TRAN / FG-TRAN series), Direct Attach Cables (FN-CABLE series) |
[/accesories]
The FortiGate 3500F Series builds security-driven networks for large enterprises and data centers using FortiOS and Fortinet’s SPU NP7 and CP9 processors.
This bundle includes Hardware + FortiCare Premium + FortiGuard Enterprise Protection (3 Year) to support and protect the deployment.
High Performance with Flexibility and Hyperscale Security
- NP7 and CP9 SPUs accelerate security inspection and SSL.
- 6x 100GE QSFP28 and 32x 25GE SFP28 connectivity.
- Integrated ZTNA enforcement controls and verifies application access.
- Supports Hyperscale Firewall License for higher sessions and CPS.
- FortiOS converged networking and security with FortiGuard Services.
- Rack-mount 2RU design for large enterprises and data centers.
Upgrade Your Network Security
Upgrade your hyperscale environment with the Fortinet FG-3500F-BDL-809-36 today.
