[shortdesc]FG-3000F-DC-BDL-809-12 NGFW, 100 GE QSFP28 + 25 GE SFP28, DC power, NP7/CP9 SPU, 33 Gbps threat protection, FortiCare Premium + FortiGuard Enterprise Protection, 1 Year.[/shortdesc]
[properties]
| Product Series |
FortiGate 3000F Series |
| SKU |
FG-3000F-DC-BDL-809-12 |
| Bundle / Subscription |
Hardware + FortiCare Premium + FortiGuard Enterprise Protection (1 Year) |
| Form Factor |
Rack Mount, 2 RU |
| Threat Protection Throughput |
33 Gbps |
| Interfaces |
6x 100 GE QSFP28/40 GE QSFP+, 16x 25 GE SFP28/10 GE SFP+/GE SFP (includes 2x HA slots), 16x 10 GE/5 GE/2.5 GE/GE RJ45, 2x 10 GE/GE RJ45 MGMT |
| Power Input |
48-60VDC |
| Dimensions (H x W x L) |
3.5 x 17.44 x 21.89 inches (88.9 x 443 x 556 mm) |
| Weight |
37.3 lbs (16.9 kg) |
[/properties]
[specifications]
| Performance / Throughput |
| IPS Throughput |
36 Gbps |
| NGFW Throughput |
34 Gbps |
| Threat Protection Throughput |
33 Gbps |
| IPv4 Firewall Throughput (1518/512/64 byte, UDP) |
397 / 389 / 221 Gbps |
| IPv6 Firewall Throughput (1518/512/86 byte, UDP) |
397 / 389 / 221 Gbps |
| Firewall Latency (64 byte, UDP) |
3.92 μs |
| Firewall Throughput (Packet per Second) |
331.5 Mpps |
| Concurrent Sessions (TCP) |
70 Million / 230 Million* |
| VPN / SD-WAN / NGFW |
| IPsec VPN Throughput (512 byte) |
105 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
40,000 |
| Client-to-Gateway IPsec VPN Tunnels |
200,000 |
| SSL-VPN Throughput |
11 Gbps |
| Concurrent SSL-VPN Users (Recommended Max, Tunnel Mode) |
30,000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
29 Gbps |
| Interfaces / Ports |
| Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots |
6 |
| Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots |
16 (include 2x HA Slots) |
| Hardware Accelerated 10 GE / 5 GE / 2.5 GE / GE RJ45 Ports |
16 |
| 10 GE / GE RJ45 Management Ports |
2 |
| USB Ports (Client / Server) |
1 / 1 |
| Console Port |
1 |
| Included Transceivers |
2x SFP+ (SR 10 GE) |
| Power / Consumption |
| Power Consumption (Average / Maximum) |
425 W / 680 W |
| DC Current (Maximum) |
15A@48V, 9A@240V |
| Heat Dissipation |
2321 BTU/h |
| Redundant Power Supplies |
Included (Default dual DC PSU for 1+1 redundancy, hot swappable) |
[/specifications]
[accesories]
| Included Transceivers |
2x SFP+ (SR 10 GE) |
| Optional Accessories |
Rack Mount Sliding Rails (SP-FG3040B-RAIL), DC Power Supply (SP-FG3800D-DC-PS), and transceiver modules/cables for 1 GE, 10 GE, 25 GE, 40 GE, and 100 GE connectivity |
[/accesories]
The FortiGate 3000F-DC is a high-performance Next-Generation Firewall (NGFW) optimized for data centers and telecommunications environments requiring DC power. This bundle (FG-3000F-DC-BDL-809-12) includes Hardware + FortiCare Premium + FortiGuard Enterprise Protection (1 Year).
Powered by Fortinet's patented SPU NP7 and CP9 processors, it delivers 33 Gbps Threat Protection throughput with 100 GE QSFP28 connectivity for high-bandwidth cores. Flexible interfaces and dual DC power supplies support DC-powered infrastructure at scale.
Hyperscale Security with DC Power for Critical Infrastructure
- 33 Gbps threat protection throughput (Enterprise Traffic Mix).
- 6x 100 GE QSFP28 / 40 GE QSFP+ slots.
- 16x 25 GE SFP28/10 GE SFP+/GE SFP slots.
- 16x 10 GE/5 GE/2.5 GE/GE RJ45 ports.
- 48-60VDC input with default dual DC PSU.
- BDL-809 includes FortiCare Premium and Enterprise Protection, 1 Year.
Upgrade Your Network Security
Deploy the FortiGate FG-3000F-DC-BDL-809-12 for DC-powered 100 GE NGFW protection.
