[shortdesc]
- 18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
[/shortdesc]
[properties]
| Properties |
FG-200E |
| Description |
18x GE RJ45 (including 2x WAN ports, 1x Mgmt port, 1x HA port, 14x switch ports), 4x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
|
| Product Family |
Mid Range Firewalls |
| Product Type |
Firewall |
| GE RJ45 Ports |
14 |
| GE RJ45 Management/DMZ/HA Ports |
2 |
| GE RJ45/SFP Shared Media Pairs |
4 |
| GE RJ45 WAN Port |
2 |
| USB Port |
1 |
| Console (RJ45) |
1 |
| Wireless Interface |
0 |
[/properties][specifications]
|
Firewall Throughput (1518 / 512 / 64 byte, UDP)
|
20 / 20 / 9 Gbps |
| Firewall Latency (64 byte UDP packets) |
3 μs |
| Firewall Throughput (Packets Per Second) |
13.5 Mpps |
| Concurrent Sessions (TCP) |
2 Million |
| New Sessions/Second (TCP) |
135.000 |
| Firewall Policies |
10.000 |
| IPsec VPN Throughput (512 byte packets) |
7.2 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
| Client-to-Gateway IPsec VPN Tunnels |
10000 |
| SSL-VPN Throughput |
900 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum) |
500 |
| SSL Inspection Throughput |
820 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
1000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
240000 |
| Application Control Throughput |
3.5 Gbps |
| IPS Throughput |
2.2 Gbps |
| NGFW Throughput |
1.8 Gbps |
| Threat Protection Throughput |
1.2 Gbps |
| CAPWAP Throughput |
1.5 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiSwitches Supported |
64 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
256 / 128 |
| Maximum Number of FortiTokens |
5000 |
| Maximum Number of Registered FortiClients |
- |
| High Availability Configurations |
Active/Active, Active/Passive, Clustering |
| Dimensions in. |
1.75 x 17.0 x 11.9 |
| Form Factor |
Rack Mount, 1 RU |
| Power Required |
100240V AC, 5060 Hz |
| Maximum Current |
100V / 3A, 240V / 0.42A |
| Power Consumption (Average / Maximum) |
70.98 / 109.9 W |
| Operating Temperature |
32104°F (040°C) |
| Regulatory Compliance |
FCC Part 15B, Class A, CE, RCM, VCCI, UL/ cUL, CB, BSMI
|
| Certifications |
USGv6/IPv6 |
[/specifications][accesories]
| FN-TRAN-GC |
1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
|
| FN-TRAN-SX |
1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots
|
| FN-TRAN-LX |
1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
|
[/accesories]
18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
This product has been discontinued.
