Description
The Eaton FG3110S02 is a molded case circuit breaker designed to provide reliable overcurrent protection in commercial and industrial electrical distribution systems. This Eaton part number FG3110S02 features a three-pole configuration with a 110 amp trip rating and a thermal-magnetic trip mechanism for dependable fault interruption. It is engineered within the EG frame platform to safeguard electrical circuits from overload and short-circuit conditions.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton |
| Category |
Circuit Breaker |
| Part Number |
FG3110S02 |
| Subcategory |
Circuit Breaker Trip |
| Breaker Type |
Molded Case Circuit Breaker |
| Frame Style |
EG Frame |
| Number of Poles |
3 Pole |
| Trip Amperage |
110 A |
| Trip Mechanism |
Thermal-Magnetic |
| Trip Unit Type |
Non-Interchangeable |
| Application |
Industrial Power Distribution |
| Mounting Type |
Panel / Switchgear Installation |
| Protection Type |
Overcurrent and Short-Circuit Protection |
| Weight |
4.00 lbs |
Information About FG3110S02
The FG3110S02 is part of Eaton’s FG series molded case circuit breaker family, designed for use in power distribution panels and industrial control systems. It incorporates a thermal-magnetic trip mechanism that combines thermal overload protection with instantaneous magnetic response to short circuits. The breaker includes a non-interchangeable trip unit, ensuring consistent factory-calibrated protection for its rated current. Built with an EG frame style housing and a three-pole configuration, it is suitable for protecting three-phase electrical circuits in commercial and industrial applications.
Key Features:
- 110 Amp Trip Rating: Provides calibrated overcurrent protection for circuits rated up to 110 A.
- Three-Pole Configuration: Designed for balanced protection in three-phase electrical systems.
- Thermal-Magnetic Trip Mechanism: Combines overload and instantaneous short-circuit protection.
- EG Frame Construction: Durable molded case design suited for industrial power distribution.
- Non-Interchangeable Trip Unit: Factory-calibrated trip unit ensures stable and consistent protection.
- Industrial Application Use: Suitable for panelboards, switchgear, and distribution systems.
- Molded Case Protection: Protects equipment and wiring from overload and fault conditions.
The FG3110S02 delivers the reliability and precision required for protecting industrial and commercial power distribution circuits.
