The QMQB2232H from Federal Pacific is a QMQB Series panel mount switch rated at 200 A, 3-pole, 240 VAC. It provides 200kA@240V interrupting rating.
Factory specification: American, QMQB Series panel mount, "H" style, 3PH, 3P, 240V, 200A, 200kA@240V, nema 1, Fusible accepts class R,H,K,J fuses, Dual/Twin style, suitable for use with QMQB and FDP style panel boards and switchgear distribution systems.
QMQB2232H Technical Specifications
| Manufacturer |
Federal Pacific |
| Series |
QMQB Series |
| Type |
Panel Mount Switch |
| Voltage |
240 V |
| Amperage |
200 A |
| Poles |
3 |
| Phase |
3 |
| AIC Rating |
200kA@240V |
| Nema Rating |
1 |
| Configuration |
Dual/Twin |
| Switch Style |
Fusible |
| Suit Fuse |
R,H,K,J |
Industrial Automation Co. offers the QMQB2232H in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
