Federal Pacific QMQB2032BV: a 200 A, 3-pole, 240 VAC QMQB Series panel mount switch. It provides 200kA@240V interrupting rating.
Factory specification: FPE,Federal Pacific, QMQB Series panel mount, "B" style, vertical mount, 3PH, 3P, 240V, 200A, 200kA@240V, nema 1, Fusible accepts class H,K,J,R fuses, Single style, suitable for use with QMQB and FDP style panel boards and switchgear distribution systems.
QMQB2032BV Technical Specifications
| Manufacturer |
Federal Pacific |
| Series |
QMQB Series |
| Type |
Panel Mount Switch |
| Voltage |
240 V |
| Amperage |
200 A |
| Poles |
3 |
| Phase |
3 |
| AIC Rating |
200kA@240V |
| Nema Rating |
1 |
| Mechanism Operator |
Manual Charge |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
H,K,J,R |
Industrial Automation Co. offers the QMQB2032BV in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
