Description
The Lenze EVF8217-E is an 8210 Series variable speed drive designed to regulate three-phase motor speed in industrial applications. Rated at 7.5 kW (15 HP), it operates on a 400 VAC input supply and provides adjustable output voltage up to 400 VAC with frequency control from 0 to 480 Hz. This frequency inverter enables efficient motor performance and precise speed adjustment in demanding automation systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Lenze |
| Category |
Drives & Motor Controls |
| Part Number |
EVF8217-E |
| Subcategory |
Variable Frequency Drives |
| Series |
8210 Series |
| Product Type |
Frequency Inverter |
| Rated Power |
7.5 kW |
| Horsepower Rating |
15 HP |
| Input Phase |
3 Phase |
| Input Voltage |
400 VAC |
| Input Frequency |
50/60 Hz |
| Input Current |
32 A |
| Output Phase |
3 Phase |
| Output Voltage |
0–400 VAC |
| Output Current |
16.5 A |
| Output Frequency |
0–480 Hz |
| Mounting Type |
Panel Mount |
| Application |
AC Motor Speed Control |
| Weight |
Approx. 8 kg |
Information About EVF8217-E
The EVF8217-E is part of the Lenze 8210 Series frequency inverter range, developed for reliable control of three-phase AC motors. It accepts a three-phase 400 VAC input at 50/60 Hz with a rated input current of 32 A and delivers controlled three-phase output at up to 16.5 A. The adjustable output frequency range of 0–480 Hz allows flexible motor speed regulation across a wide operational spectrum. Designed for panel mounting in industrial control cabinets, it is commonly used in pumps, fans, conveyors, and processing equipment.
Key Features:
- 7.5 kW / 15 HP Rating: Suitable for medium-power industrial motor applications.
- Three-Phase 400 VAC Input: Operates on standard industrial power systems.
- Adjustable Output Voltage: Provides 0–400 VAC for controlled motor operation.
- Wide Frequency Range: Output frequency adjustable from 0 to 480 Hz.
- 32 A Input Current: Supports stable power input for continuous operation.
- 16.5 A Output Current: Delivers consistent motor drive performance.
- 8210 Series Platform: Designed for dependable AC motor speed control.
- Industrial Panel Integration: Engineered for installation in control cabinets.
The EVF8217-E delivers the reliability and precision required for variable speed control of three-phase industrial motors.
