| Product Configurations |
Performance and capacity for you remote or branch office data center |
| Storage Controllers |
Dual controllers with 4GB non-volatile memory per controller |
| Network Interfaces |
Management Network: 1x 100BASE-TX per controller; Interfaces Ports: 1x 10GBASE-T with RJ45 and 1x 10GbE SFP+ for fibre or twin-ax copper cabling |
| Hard Disk Drives |
24x Hot-Pluggable 2.5" 10K SAS |
| Drive Capacities |
300GB, 600GB, 900GB 10K SAS |
| System Capacities |
Up to 21.6TB |
| Host Protocol |
Any standards-compliant iSCSI initiator |
| Volumes |
Up to 256 |
| Snapshots |
128 per volume/up to 2,048 total per group |
| Volume Connections per PS Series Group |
Up to 512 per pool/1024 per group |
| OS and Hypervisors Supported |
Microsoft Windows Server including Hyper-V, VMware ESX Server, Red Hat Enterprise Linux (RHEL), SUSE Enterprise Linux (SLES), Oracle Linux, Oracle Solaris, IBM AIX, HP-UX, Mac OS X, Citrix XenServer, Novell NetWare |
| RAID Supported |
RAID 5, RAID 6, RAID 10, RAID 50 |
| TCP Network Support |
IPv4, IPv6 Core Support |
| Expansion Option |
Can be combined with other EqualLogic PS Series arrays in the same SAN group online. A maximum of two (2) PS4x00 Arrays can be in a group |
| Reliability |
Vertical port sharing. Redundant Hot-Swappable controllers, power supplies, cooling fans and hot-swappable disks. Individual disk drive slot power control. |
| Enclosure Monitoring System |
Automatic spare configuration and utilization; SMART; Automatic bad block replacement; Auto-Stat Disk Monitoring System (ADMS) to monitor health of data on disk drives |
| Management Interfaces |
EqualLogic SAN Headquarters multi-group performance and event monitoring tool. Serial Console. Ability to configure a separate management network. SNMP, Telnet, SSH, HTTP, Web (SSL), Host Scripting. Multi-administrator support. |
| Security |
CHAP Authentication; Access control for iSCSI; Access control for management interfaces including RADIUS support |
| Notification Methods |
SNMP traps, e-mail, syslog |
| Physical |
Height: 2U (3.41") Width: 17.57" Depth: 21.3" Weight: 53.1 lbs |
| Power |
Dual 700W Power Supplies. AC Voltage: 100-240 VAC. 700W (max, total). Frequency: 50/60 Hz |
| Rack Support |
ReadyRails II static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded-hole racks |
