Description
The Eaton EGB2020FFG is a molded case circuit breaker designed to provide dependable overcurrent protection in commercial and industrial electrical systems. This 2-pole breaker features a 20 amp rating and supports high-voltage distribution up to 600Y/347VAC with thermal magnetic protection. Built for panel-mounted installations, the EGB2020FFG ensures consistent circuit protection and operational safety.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton |
| Category |
Circuit Breaker |
| Part Number |
EGB2020FFG |
| Subcategory |
Molded Case Circuit Breaker |
| Series |
Series G |
| Frame Type |
EG Frame |
| Breaker Type |
Complete Breaker |
| Amperage Rating |
20 A |
| Voltage Rating |
600Y/347 VAC |
| Number of Poles |
2 |
| Phase |
Single Phase |
| Frequency Rating |
50/60 Hz |
| Trip Unit Type |
Thermal Magnetic (Fixed) |
| Trip Functions |
Long-Time and Instantaneous |
| Interrupt Rating |
25 kAIC @ 240 VAC; 18 kAIC @ 480 VAC |
| Mounting Type |
Panel Mount |
| Connection Type |
Feed-Thru |
| Terminal Type |
Line and Load Side Lugs |
| Actuator Type |
Toggle |
| Body Material |
Glass Polyester |
| Operating Temperature |
-20°C to 70°C |
| Certifications |
UL Listed, IEC Rated, CSA Certified, CE Marked |
| Dimensions (H × W × D) |
5.5 in × 2 in × 2.99 in |
| Weight |
2 lb |
Information About EGB2020FFG
The EGB2020FFG is an Eaton Series G molded case circuit breaker built on the EG-frame platform for compact and reliable performance. It incorporates a fixed thermal and fixed magnetic trip system to provide long-time and instantaneous fault protection without adjustment complexity. This complete breaker is designed for use in panelboards and switchgear requiring high-voltage AC ratings and multi-standard compliance. With support for global certifications, it is suitable for installations in regulated industrial and commercial environments operating at 50/60 Hz.
Key Features:
- 20 Amp Current Rating: Designed for branch circuit protection in high-voltage systems
- 2-Pole Configuration: Provides coordinated protection across two conductors
- Thermal Magnetic Trip Unit: Ensures reliable long-time and instantaneous fault response
- High Interrupt Capacity: Rated at 25kAIC at 240VAC and 18kAIC at 480VAC
- Panel Mount Design: Allows secure integration into control panels and distribution equipment
- EG-Frame Construction: Compact molded case design for efficient space utilization
- Wide Certification Support: Approved to UL, IEC, CSA, CE, IEEE, and CCC standards
The EGB2020FFG delivers the reliability and precision required for high-voltage circuit protection in industrial and commercial power distribution systems.
