Description
The Eaton EDH2200 is a 2-pole molded case circuit breaker designed to provide dependable overcurrent protection in commercial and industrial electrical systems. This breaker supports 200-amp circuits at 240VAC or 125VDC and delivers high interrupting performance for demanding applications. The EDH2200 is suitable for installations requiring a compact F-Frame device with fixed thermal-magnetic trip technology.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton / Cutler-Hammer |
| Category |
Molded Case Circuit Breaker |
| Part Number |
EDH2200 |
| Subcategory |
2-Pole Circuit Breaker |
| Series |
Series C |
| Frame Type |
F-Frame |
| Amperage Rating |
200A |
| Voltage Rating |
240VAC, 125VDC |
| Poles |
2 |
| Interrupting Rating |
100kAIC @ 240VAC |
| Trip Type |
Thermal-Magnetic |
| Trip Functions |
Long-Time & Instantaneous |
| Connection Type |
Bolt-On |
| Terminals |
Load Side |
| Frequency Rating |
50–60 Hz |
| Circuit Breaker Type |
EDH |
| Dimensions (H × W × D) |
6 in × 2.75 in × 3.38 in |
| Weight |
3 lb |
Information About EDH2200
The EDH2200 is a Series C molded case circuit breaker built with an F-Frame housing designed for durable operation in distribution equipment. It incorporates a fixed thermal-magnetic trip unit that supports long-time and instantaneous protection functions. The breaker is compatible with bolt-on mounting systems commonly used in panelboards and switchgear. Its UL-listed construction and load-side terminals make it suitable for both new assemblies and replacement applications.
Key Features:
- Series C Platform: Built on Eaton’s standard Series C architecture for reliable system integration.
- Fixed Thermal-Magnetic Trip: Provides overload and short-circuit protection with stable trip characteristics.
- High Interrupt Rating: Rated up to 100kAIC at 240VAC for demanding fault conditions.
- Bolt-On Connection: Ensures secure installation in panelboards and distribution equipment.
- F-Frame Construction: Compact design supports high-capacity performance in limited spaces.
- UL Listed Compliance: Verified to meet recognized electrical safety and performance standards.
- Load-Side Terminals: Enables straightforward conductor attachment for distribution circuits.
The EDH2200 delivers the reliability and precision required for molded case overcurrent protection in electrical distribution systems.
