Description
The Eaton NDC3800T52WPN is a Series G electronic molded case circuit breaker designed for high-capacity power distribution and protection. Eaton NDC3800T52WPN provides precise overload and short-circuit protection using an advanced electronic LSI trip system. It is suited for industrial and commercial installations requiring reliable interruption performance and system monitoring capability.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton |
| Category |
Circuit Protection |
| Part Number |
NDC3800T52WPN |
| Subcategory |
Molded Case Circuit Breakers |
| Product Type |
Electronic molded case circuit breaker |
| Series |
Series G |
| Design |
OPTIM 550 |
| Frame |
NG |
| Circuit Breaker Type |
NDC |
| Frame Type |
Complete breaker |
| Amperage Rating |
800 A |
| Voltage Rating |
600 Vac |
| Trip Type |
Electronic LSI |
| Number of Poles |
Three-pole |
| Interrupt Rating |
100 kAIC at 480 Vac |
| Interrupt Rating (Alt.) |
200 kAIC at 240 Vac |
| Terminals |
Without terminals |
| Accessories |
PowerNet kit compatible |
| Compliances |
HACR Rated |
| Product Length/Depth |
5.5 in |
| Product Height |
8.25 in |
| Product Width |
8.25 in |
| Weight |
46 lb |
Information About
NDC3800T52WPN
The NDC3800T52WPN is part of Eaton’s Series G family, featuring the OPTIM 550 design for enhanced protection and system integration. It is built on an NG frame with a complete breaker configuration, supporting three-phase electrical systems up to 800 A. The breaker incorporates an electronic LSI trip unit, offering adjustable long-time, short-time, and instantaneous protection for optimized coordination. Additionally, it includes compatibility with PowerNet communication kits, enabling advanced monitoring and integration into facility power management systems.
Key Features:
- Series G Construction: Engineered for durability and performance in demanding power systems.
- 800 A Rating: Suitable for high-load distribution circuits and industrial equipment.
- Electronic LSI Trip Unit: Provides adjustable long-time, short-time, and instantaneous protection.
- High Interrupt Capacity: Up to 100 kAIC at 480 Vac for effective fault interruption.
- NG Frame Design: Supports heavy-duty applications and system scalability.
- Three-Pole Configuration: Designed for three-phase electrical systems.
- PowerNet Compatibility: Enables communication and monitoring through optional accessories.
- HACR Rated: Approved for heating, air conditioning, and refrigeration equipment applications.
The NDC3800T52WPN delivers the reliability and precision required for protecting large-scale electrical distribution systems in commercial and industrial environments.
