Description
The Eaton HFD3015VH09 is a Series C molded case circuit breaker designed to provide dependable overcurrent protection in commercial and industrial electrical distribution systems. Eaton part number HFD3015VH09 features a 15 A rating with a three-pole configuration and a thermal-magnetic T186 trip unit for accurate response to overload and short-circuit conditions. Its high interrupt capacity and naval-class construction ensure reliable operation in demanding environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton |
| Category |
Circuit Protection |
| Part Number |
HFD3015VH09 |
| Subcategory |
Molded Case Circuit Breaker |
| Product Type |
Molded case circuit breaker |
| Series |
Series C |
| Circuit Breaker Type |
HFD |
| Frame |
F |
| Circuit Breaker Frame Type |
Complete breaker |
| Amperage Rating |
15 A |
| Voltage Rating |
600 Vac / 250 Vdc |
| Trip Type |
T186 thermal-magnetic |
| Number of Poles |
Three-pole |
| Frequency Rating |
50/60 Hz |
| Calibration |
50 °C |
| Class |
Naval |
| Terminals |
Load side |
| Interrupt Rating |
100 kAIC at 240 Vac |
| Additional Interrupt Rating |
65 kAIC at 480 Vac |
| Certification |
UL 489 |
| Product Dimensions (L × W × H) |
3.38 × 4.13 × 6 in |
| Warranty |
Eaton Selling Policy 25-000 |
| Weight |
4.5 lb |
Information About HFD3015VH09
The HFD3015VH09 is a complete molded case circuit breaker from Eaton’s Series C circuit protection family. Built on the F-frame platform, it incorporates a T186 thermal-magnetic trip mechanism that provides both long-time overload protection and instantaneous fault interruption. The breaker includes load-side terminals and is calibrated for operation at 50 °C, making it suitable for installations with elevated ambient temperatures. With UL 489 certification and a naval-class rating, it is engineered for reliable use in commercial, industrial, and specialized marine or defense-related electrical systems.
Key Features:
- 15 Amp Current Rating: Provides reliable protection for branch circuits and low-current feeder applications.
- Series C Breaker Platform: Eaton’s proven molded case circuit breaker design for consistent performance and durability.
- T186 Thermal-Magnetic Trip Unit: Detects overload and short-circuit faults for accurate circuit protection.
- High Interrupting Capacity: Rated up to 100 kAIC at 240 Vac for safe interruption of large fault currents.
- Three-Pole Configuration: Suitable for protecting three-phase electrical distribution circuits.
- Naval-Class Construction: Designed to meet demanding reliability requirements in specialized installations.
- 50 °C Calibration: Maintains accurate protection performance in elevated ambient temperature environments.
- Load-Side Terminal Configuration: Enables secure conductor connection and simplified installation.
The HFD3015VH09 delivers the reliability and precision required for protecting critical electrical circuits in industrial, commercial, and specialized marine power systems.
