Description
The DC2500-E0-0L00-200-10000-00-0 is a ¼ DIN universal digital controller designed for process and temperature control in industrial environments. Powered by 90–264 VAC, it features limit control functionality with a relay output. It accommodates a range of analog inputs—TC, RTD, mV, 0–5 V, and (0) 4–20 mA—making it versatile for monitoring diverse field signals.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Honeywell |
| Category |
|
| Part Number |
DC2500-E0-0L00-200-10000-00-0 |
| Subcategory |
Temperature/Process Control |
| Product Series |
UDC2500 Universal Digital Controller |
| Controller Size |
¼ DIN (96 × 96 mm) |
| Power Supply |
90–264 VAC (also available in 24 VAC/DC variant) |
| Analog Inputs |
Input 1: TC/RTD/mV/0–5 V/(0) 4–20 mA; Input 2: 0–5 V/1–5 V/0–20 mA/4–20 mA |
| Analog Input Accuracy |
±0.25% of full scale; 16-bit resolution |
| Scan Rate |
166 ms |
| Limit Output Relay |
One electromechanical relay with manual/remote reset |
| Software Features |
Accutune III™, fuzzy tuning, ramp/soak, remote setpoint, multilang prompts |
| Display |
Vacuum fluorescent dual display (PV + SP or status) |
| I/O Isolation |
Yes |
| Front Panel Protection |
NEMA4X/IP66 (wash-down capable) |
| Digital Inputs |
Two isolated dry-contact inputs |
| Communications |
Optional Ethernet TCP/IP, Modbus RTU, infrared PC connectivity |
| Certifications |
CE, UL, CSA, FM |
| Operating Temperature |
Up to 55 °C (133 °F) front bezel withstands shock/vibration |
| Configuration |
Jumper-free via front keypad or software |
| Mounting |
Panel cut-out 92 × 92 mm (mount thickness 16–63 mm) |
| Weight |
Approximately 3 lb (1.3 kg) |
Information About DC2500-E0-0L00-200-10000-00-0
The DC2500-E0-0L00-200-10000-00-0 is a Honeywell UDC2500 series controller built for precise limit-based process regulation. It offers a rugged ¼ DIN form factor with NEMA4X/IP66-rated front panel protection. Equipped with one universal input and one high-level input, it supports internal software Accutune™ tuning and limit control models. Certified to CE, UL, CSA, and FM standards, this controller fits applications ranging from furnaces and ovens to packaging and environmental chambers.
Key Features:
- ¼ DIN Form Factor: Compact panel-mount digital controller.
- Universal Input: Accepts TC, RTD, mV, 0–5 V, and (0) 4–20 mA signals.
- High-Level Input: Second channel for 0–5 V, 1–5 V, 0–20 mA, or 4–20 mA signals (e.g., remote setpoint).
- Limit Control Relay: One relay output for high or low trip with manual or remote reset.
- Accutune™ III: Built-in PID tuning with fuzzy overshoot suppression for faster response.
- Durable Construction: NEMA4X/IP66-rated front bezel for wash-down applications.
- Robust Software Interface: Multilanguage prompts and jumper-free configuration.
- Isolated I/O: Inputs and outputs are electrically isolated for noise immunity.
- Industrial Communications: Optional Ethernet, Modbus RTU, and infrared PC configuration.
- Wide Power Range: Operates on 90–264 VAC or 24 VAC/DC (model dependent).
- The DC2500-E0-0L00-200-10000-00-0 delivers the reliability and precision required for industrial limit and process control applications.
