Description
The Beckhoff CX2020-0155 PLC module is a modular DIN rail industrial PC designed for advanced PLC and automation control tasks. It is powered by an Intel Celeron 827E processor and runs Windows 10 IoT Enterprise with TwinCAT 3 runtime support. This controller provides reliable real-time performance for machine and process automation systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Beckhoff |
| Category |
Industrial Automation |
| Part Number |
CX2020-0155 |
| Subcategory |
PLC Modules |
| Processor |
Intel Celeron 827E |
| Clock Frequency |
1.4 GHz |
| CPU Cores |
1 |
| Operating System |
Windows 10 IoT Enterprise 2016 LTSB |
| Control Software |
TwinCAT 3 Runtime (XAR) |
| Main Memory |
2 GB DDR3 RAM (Expandable to 4 GB) |
| Flash Storage |
40 GB CFast |
| NVRAM |
128 kB |
| Ethernet Ports |
2 × RJ45 10/100/1000 Mbps |
| USB Ports |
4 × USB 2.0 |
| Video Interface |
1 × DVI-I |
| I/O Bus Connection |
E-bus or K-bus |
| Power Supply |
24 V DC (−15% / +20%) |
| Max Power Consumption |
21 W |
| Cooling Method |
Passive (Optional Active Cooling) |
| Diagnostic LEDs |
Power, TC, Flash, Bus Status |
| Weight |
1.16 kg |
Information About CX2020-0155
The CX2020-0155 is part of Beckhoff’s CX2000 series of embedded industrial PCs, engineered for scalable and high-performance automation applications. It features a fanless design with optional active cooling to support continuous industrial operation. The controller includes expandable memory, CFast flash storage, and battery-backed NVRAM for data retention. With automatic E-bus and K-bus recognition, it integrates seamlessly with Beckhoff I/O systems and EtherCAT terminals.
Key Features:
- Intel Celeron 827E Processor: Single-core CPU operating at 1.4 GHz for reliable PLC execution.
- TwinCAT 3 Runtime Support: Designed for modern PLC and automation software environments.
- Windows 10 IoT Enterprise OS: Provides long-term support and industrial-grade stability.
- Modular DIN Rail Design: Optimized for flexible control cabinet installations.
- Expandable Memory Architecture: Includes 2 GB DDR3 RAM, expandable up to 4 GB.
- Integrated CFast Storage: Supplied with 40 GB CFast flash memory for system and application data.
- Extensive Connectivity Options: Dual Gigabit Ethernet, USB, and DVI-I interfaces.
The CX2020-0155 delivers the reliability and precision required for PLC-based industrial automation and control systems.
