Description
The Cognex DMR-362X-1000 is a high-performance fixed-mount industrial barcode reader from the DataMan 360 Series, engineered for reliable 1D, 2D, and Direct Part Mark (DPM) code reading in demanding manufacturing environments. Featuring a 1.2 MP global shutter image sensor, advanced Cognex decoding technologies, and industrial Ethernet connectivity, it delivers fast and accurate barcode identification on high-speed production lines.
Technical Specifications
| Condition |
Obsolete / Surplus Available |
| Brand |
Cognex |
| Part Number |
DMR-362X-1000 |
| Category |
Bar Code Equipment |
| Subcategory |
Bar Code Scanner Industrial |
| Product Type |
Fixed-Mount Barcode Reader |
| Series |
DataMan 360 |
| Image Sensor |
1.2 MP CMOS, Global Shutter |
| Resolution |
1280 × 1024 (SXGA) |
| Frame Rate |
60 fps |
| Supported Codes |
1D, 2D, Direct Part Mark (DPM) |
| Decoding Technologies |
1DMax®, 2DMax®, IDQuick® |
| Communication |
Ethernet, RS-232 |
| Digital Inputs |
4 (1 Trigger + 3 Discrete) |
| Digital Outputs |
4 (Sink/Source, 50 mA) |
| Supply Voltage |
24 VDC |
| Memory Expansion |
MicroSD Card Slot |
| Mounting Type |
C-Mount / S-Mount |
| Protection Rating |
IP65 |
| Replacement Model |
DMR-363X-1000 |
| Weight |
0.40 lbs |
Information About DMR-362X-1000
The DMR-362X-1000 is part of Cognex's DataMan 360 Series of industrial barcode readers. It features a 1280 × 1024 (SXGA) CMOS image sensor with a global shutter operating at up to 60 frames per second, ensuring reliable code reading on moving objects. The reader supports Cognex's advanced 1DMax®, 2DMax®, and IDQuick® decoding technologies for exceptional performance on damaged or low-quality barcodes. Designed for fixed-mount industrial applications, it offers Ethernet and RS-232 communication, multiple digital I/O, MicroSD storage, and an IP65-rated enclosure for dependable operation in harsh industrial environments. This model has been discontinued and replaced by the DMR-363X-1000.
Key Features:
- DataMan 360 Series fixed-mount barcode reader
- 1.2 MP (1280 × 1024) global shutter CMOS sensor
- Up to 60 fps image acquisition
- Reads 1D, 2D, and Direct Part Mark (DPM) codes
- 1DMax®, 2DMax®, and IDQuick® decoding technologies
- Omnidirectional 1D barcode reading
- Ethernet and RS-232 communication interfaces
- IP65-rated industrial enclosure
- MicroSD card slot for data storage
- Designed for industrial automation, inspection, and traceability
The DMR-362X-1000 delivers reliable barcode reading performance for demanding industrial manufacturing and logistics applications.
