[properties]
| Properties |
Cisco SFP-10G-LR-X multirate 10GBASE-LR, 10GBASE-LW and OTU2e SFP+ Module |
| Description |
The Cisco SFP-10G-LR-X is a multi-rate 10GBASE-LR, 10GBASE-LW, and OTU2/OTU2e module for an extended operating temperature range. It supports a link length of 10 kilometers on standard Single-Mode Fiber |
| Product Family |
Cisco 10GBASE SFP+ Modules |
| Product Type |
Module |
[/properties] [specifications]
| Specifications |
Multirate 10GBASE-LR, 10GBASE-LW, and OTU2e SFP+ Module for SMF, extended temperature range |
| Wavelength (nm) |
1310 |
| Cable Type |
SMF |
| Core Size (Microns) |
G.652 |
Modal Bandwidth (MHz* km) **
|
(-) |
| Cable Distance* |
10km |
*Minimum cabling distance for -SR, -LRM, -LR, -ER modules is 2m, according to the IEEE 802.3ae
**Specified at transmission wavelength |
| Type |
10GBASE-LR, 10GBASE-LW and OTU2e 1310nm SMF |
| Transmit Power (dBm)* |
Maximum: 0.5
Maximum: -8.2 |
| Receive Power (dBm)* |
Maximum: 0.5
Maximum: -14.4 |
| Transmit and Receive Wavelength (nm) |
1260 to 1355 |
*Transmitter and receiver power is on average unless specified. |
| Power Consumption (W) |
1 |
| Operating Temperature Range |
EXT |
[/specifications] [accesories] [/accesories] Multirate 10GBASE-LR, 10GBASE-LW and OTU2e SFP+ Module for SMF, extended temperature range
