[properties]

Properties	C9200L-24T-4G-A
Description	Catalyst 9200L 24-port Data 4x1G uplink Switch, Network Advantage
Product Family	Catalyst 9200-L
Product Type	Ethernet Switch
Number of Ports	24
Downlinks total 10/100/1000 or PoE+ copper ports	24 ports data
Uplink configuration	4x 1G fixed uplinks‚
Cisco IOS Software	Network Advantage
Default primary AC power supply	PWR-C5-125WAC
Available PoE power with additional secondary power supply
Fans	Fixed redundant
Chassis + FEP + ‚ Fan Dimensions (HxWxD) Inches	1.73 x 17.5 x 11.3

[/properties][specifications]

Specifications	C9200L-24T-4G-A
Console Ports	RJ-45-to-DB9 cable for PC connections, USB-C adaptor, USB adaptor
DRAM	2 GB
Flash Memory	4 GB
Switching capacity	56 Gbps
Forwarding rate‚	41.66 Mpps
MAC addresses	16000
Operating Temperature Up to 5,000 ft (1500 m)	-5°C to +45°C
Operating Temperature Up to 10,000 ft (3000 m)	-5°C to +40°C
Safety	IEC 60950-1 UL 60950-1 CAN/CSA C22.2 No. 60950-1 EN 60950-1 AS/NZS 60950.1 Class I Equipment
Electromagnetic compatibility certifications	47 CFR Part 15 CISPR 32 Class A CNS 13438 EN 300 386* EN 55032 Class A EN61000-3-2 EN61000-3-3 ICES-003 Class A KN 32 TCVN 7189 Class A V-3 Class A CISPR 35 EN 300 386* EN 55035 KN 35 TCVN 7317
EMC compliance	FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55032 Class A CISPR 32 Class A AS/NZS 3548 Class A BSMI Class A VCCI Class A CISPR 35 EN 55035, EN300 386* EN 61000-3-2, EN 61000-3-3
Safety compliance	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
Environmental	Reduction of Hazardous Substances (ROHS) 5

[/specifications][accesories]

Stacking Support	StackWise-80‚
Stacking bandwidth support	80 Gbps
Stacking hardware‚	C9200L-STACK-KIT
Number of members	8
Supported stack members	Other C9200L models with the same license level
Stacking accessories
C9200L-STACK-KIT	Stack kit for C9200L SKUs only: Two data stack adapters and one data stack cable
STACK-T4-50CM	Data stack 50 cm cable (default cable with Stack Kit)
STACK-T4-1M	Data stack 1 m cable
STACK T4-3M	Data stack 3 m cable
Mounting Accessories
ACC-KIT-T1=	Accessory kit with 19-inch Type 1 rack mount
RACK-KIT-T1=	19, 23, 24 inches and ETSI Type 1 rack mount kit
4PT-KIT-T2=	4 Point rack mount kit New
C9K-MGNT-TRAY	Magnet and Mounting Tray for compact switches
C9K-CMPCT-DIN-MNT	DIN Rail Mount for compact switches
RACKMNT-19-CMPACT	19-Inch Rack Mounting Brackets for compact switches
C9K-CMPCT-CBLE-GRD	Cable guard for compact switches (for C9K-WALL-TRAY)
C9K-WALL-TRAY	Wall mount bracket for compact switches
C9K-CMPCT-DESK-MNT	Under desk mount for compact switches

[/accesories]

Technical Details

The Cisco Catalyst 9200L C9200L-24T-4G-A is a Layer 3 managed 1U rackmount switch with 24 Gigabit Ethernet (10/100/1000) data ports and four fixed 1G SFP uplinks, running Cisco IOS XE with the perpetual Network Advantage license. It supports Cisco StackWise-80 stacking of up to eight C9200L members at 80 Gbps. The switch does not support Power over Ethernet, so all 24 access ports are data-only. It is built for wired access in branch and campus networks that connect non-powered endpoints such as desktops, printers, and servers.

Overview

The Cisco Catalyst C9200L-24T-4G-A is a fixed-configuration, data-only (non-PoE) Layer 3 access switch in the Cisco Catalyst 9200L series. It provides 24 Gigabit Ethernet copper access ports and four fixed 1G SFP uplink ports, and ships with the perpetual Network Advantage software license.

The Catalyst 9200L line uses fixed (non-modular) uplinks and fixed redundant fans, supports StackWise-80 stacking, and runs Cisco IOS XE on the Cisco UADP 2.0 Mini ASIC. It supports dual field-replaceable power supplies for power redundancy. On this model, the Network Advantage license adds Layer 3 routing protocols including OSPF, EIGRP, and IS-IS, along with network segmentation features such as VRF and SGT.

Part Number Decode

• C9200L indicates the fixed-uplink platform within the Cisco Catalyst 9200 Series.
• 24 indicates 24 Gigabit Ethernet access ports.
• T indicates data-only ports with no Power over Ethernet.
• 4G indicates four fixed 1G SFP uplink ports.
• -A indicates the perpetual Network Advantage license.

Best For

The C9200L-24T-4G-A suits wired access layers in branch offices, campuses, and mid-sized networks that connect non-powered devices — desktops, printers, servers, and wired IoT — and need Layer 3 routing out of the box. The Network Advantage license enables routing protocols such as OSPF, EIGRP, and IS-IS together with VRF and SGT segmentation, and StackWise-80 lets up to eight units operate as a single managed stack. The four fixed 1G SFP uplinks connect the access layer to a distribution or core tier over fiber or copper SFP.

Not suitable if:

• You need to power wireless access points, IP phones, or IP cameras over the network — this model has no PoE.
• You need 10G uplinks — the fixed uplinks run at 1G.
• You need more than 24 access ports in a single unit.
• You need multigigabit (mGig) access ports above 1G.
• You only need basic Layer 2 switching — a lower license tier covers that at lower cost, and the Network Advantage routing would go unused.

Compare Models

• Choose the C9200L-24T-4G-E if you only need Layer 2 and basic routing (Network Essentials) at a lower price on identical data-only hardware.
• Choose the C9200L-24T-4X-A if you need 10G uplinks instead of 1G.
• Choose the C9200L-24P-4G-A if you need PoE+ to power wireless access points, IP phones, or cameras.
