Description
The CIMR‑V7AU40P7 is a high-performance AC drive (inverter) from Omron’s Varispeed V7 series, delivering 4.0 kW output for 380–460 VAC three-phase systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
|
| Part Number |
CIMR-V7AU40P7 |
| Subcategory |
Drives |
| Series / Model |
PC7 / Mini Vector |
| Input Specifications |
4.7 A / 3-Phase / 380–460 VAC / 50/60 Hz |
| Output Specifications |
3.4 A / 3-Phase / 0–460 VAC / 0–400 Hz |
| Weight |
3.25 lbs |
Information About CIMR-V7AU40P7
The CIMR-V7AU40P7 is a compact AC drive from Omron’s Varispeed V7 series, designed for efficient motor control in industrial applications. This inverter operates on three-phase 380–460 VAC input, delivering precise control with sensorless vector technology. It provides a 4.0 kW output capacity, offering full torque down to 0.5 Hz, making it suitable for variable speed drive applications requiring reliable torque at low speeds. Equipped with built-in protections and a modular communication interface, the CIMR-V7AU40P7 remains a trusted solution for legacy installations despite its discontinued status.
Key Features:
- AC Drive (Inverter): Engineered for industrial motor speed and torque control using sensorless vector technology.
- 4.0 kW Output Capacity: Supports up to 4.0 kW motor loads for small to mid-sized industrial equipment.
- Three-Phase 380–460 VAC Input: Designed for standard industrial power supplies.
- Sensorless Vector Control: Delivers full torque at low speeds (down to 0.5 Hz) without the need for an encoder.
- 0–400 Hz Frequency Output: Allows precise speed control across a wide frequency range.
- Built-in PID Controller: Supports direct process control without external PLC input.
- Fieldbus Compatibility: Supports Modbus, DeviceNet, Profibus, and other protocols via optional expansion modules.
- Overload Protection: Offers 150% overload handling for up to 60 seconds.
- Detachable Digital Operator: Enables parameter setting, monitoring, and cloning via front-mounted control panel.
- IP20 Enclosure: Durable, compact housing with built-in EMC filtering (Class B).
- Global Certifications: CE, UL, and cUL compliant for worldwide industrial applications.
The CIMR-V7AU40P7 provides versatile and precise motor control in a compact, user-friendly design. Ideal for machine retrofits or maintaining existing systems, this inverter delivers reliable performance with integrated protections and flexible communication options, making it a proven solution for legacy motor control environments.
