[shortdesc] 60ppm scan speed, 120ipm duplex, 100-sheet ADF, WiFi Ethernet USB 3.0, 10.9cm touchscreen [/shortdesc]
[properties]
| Model |
Brother ADS-4900W |
| Product Type |
Professional Desktop Document Scanner |
| Scanner Type |
Dual CIS (Contact Image Sensor), LED Array Light Source |
| Scan Speed (Simplex) |
Up to 60 ppm |
| Scan Speed (Duplex) |
Up to 120 ipm |
| Optical Resolution |
Up to 600 x 600 dpi |
| Interpolated Resolution |
Up to 1200 x 1200 dpi |
| Colour Depth |
48-bit internal / 24-bit external |
| Grey Scale |
256 levels (8-bit) |
| ADF Capacity |
100 sheets |
| Display |
10.9 cm colour touchscreen |
| Connectivity |
USB 3.0, USB Host, Ethernet, Wi-Fi (2.4GHz and 5GHz) |
| Wired Network |
10Base-T / 100Base-TX |
| Wireless Network |
IEEE 802.11a/b/g/n (2.4GHz and 5GHz) |
| Wi-Fi Direct |
Supported |
| Mobile Scanning |
Supported (Brother Mobile Connect) |
| Scan Destinations |
PC, Network (SMB), Email Server, FTP/SFTP, SharePoint, USB, HTTP(S), Cloud Services |
| File Formats |
PDF (incl. secured, signed, PDF/A), JPEG, TIFF |
| Daily Duty Cycle |
Up to 9,000 sheets |
| Monthly Duty Cycle |
Up to 180,000 sheets |
| Dimensions (W x D x H) |
300 x 247 x 236 mm |
| Weight |
3.37 kg |
| Power Supply |
AC 100-240V, 50/60Hz / DC 24V, 1.9A |
| Power Consumption |
Scanning 34W; Ready 7.7W; Sleep 1.7W |
| Operating Temperature |
5°C to 35°C |
| Operating Humidity |
20% to 80% |
[/properties]
[specifications]
| Scanning Features |
Auto Deskew, Auto Image Rotation, Blank Page Removal, Edge Fill, Punch Hole Removal, Moiré Reduction, Vertical Streak Reduction |
| Feed Control |
Ultrasonic Multi-feed Sensor, Separation Switch, Scan Preview, CIS Cleaning Alarm |
| Scan Profiles |
Up to 25 preset scan profiles |
| Direct Scan |
USB flash memory support |
| Advanced Functions |
Barcode Detection, Digital Imprinter, Continuous Scan, Document Separation |
| Media Sizes |
Width 50.8-215.9 mm, Length 50.8-355.6 mm, Long paper up to 5000 mm |
| Media Weight |
25-413 gsm |
| Plastic Card Support |
Up to 1.32 mm embossed |
| Supported Media |
Plain, Thin, Thick, Recycled Paper, Business Card, Plastic Card |
| Software Support |
TWAIN, ISIS, WIA, SANE |
| Operating Systems |
Windows, macOS, Linux |
| Cloud Integration |
Google Drive, OneDrive, SharePoint, Dropbox, Evernote |
| Security Features |
SSL/TLS, SNMP v3, 802.1x, WPA3, LDAP, Secure Function Lock |
| Network Protocols |
IPv4/IPv6, DHCP, DNS, SNMP, HTTP/HTTPS |
| Noise Level |
Less than 62 dB (scanning) |
[/specifications]
[accesories]
| Included |
ADS Scanner, Detachable ADF, Power Cord, AC Adapter, USB Cable, Quick Setup Guide, Product Safety Guide |
| Optional |
A3 Carrier Sheet (CS-A3301), Roller Kit (PRK-A4001) |
[/accesories]
Accelerate Document Workflows with Enterprise-Grade Scanning
The Brother ADS-4900W is a high-performance desktop document scanner designed for demanding business environments. Built for fast, secure, and flexible document capture, it combines ultra-fast scanning speeds with advanced connectivity and intelligent image processing. Ideal for offices handling high-volume workflows, it ensures seamless digitization and efficient collaboration across teams.
Key Benefits and Features
-
Ultra-Fast Scanning Performance: Capture up to 60 pages per minute and 120 images per minute duplex, enabling rapid batch processing for high-volume document workflows.
-
Large 100-Sheet ADF: Handle continuous scanning jobs with a high-capacity automatic document feeder, minimizing manual intervention and increasing productivity.
-
Advanced Connectivity Options: Supports USB 3.0, wired Ethernet, and dual-band WiFi including 5GHz for flexible deployment and secure network integration.
-
Intuitive Touchscreen Interface: The 10.9cm color touchscreen allows one-touch scanning and up to 56 customizable shortcuts for streamlined operations.
-
Intelligent Image Processing: Features ultrasonic multi-feed detection, blank page removal, moiré reduction, and barcode recognition for optimized output quality.
Ideal Use Cases
- High-volume office document digitization
- Finance and legal document processing
- Healthcare records and compliance scanning
- Remote and hybrid workforce document sharing
- Enterprise workflow automation and archiving
Technical Specifications
-
Scan Speed: Up to 60 ppm / 120 ipm duplex
-
ADF Capacity: 100 sheets
-
Optical Resolution: Up to 600 x 600 dpi
-
Connectivity: USB 3.0, USB Host, Ethernet, WiFi 2.4GHz and 5GHz
-
Display: 10.9cm color touchscreen
-
Daily Duty Cycle: Up to 9,000 sheets
-
Monthly Volume: Up to 180,000 sheets
-
Media Support: Paper, plastic cards, business cards, long documents
-
File Formats: PDF, PDF/A, JPEG, TIFF
Upgrade Your Scanning Efficiency Today
Transform your document workflows with speed, precision, and reliability. Order today and streamline your business operations.
