Description
The Eaton BABRSP1030 is a single-pole, 30-amp molded case circuit breaker designed for reliable electrical protection in low-voltage panelboard systems. This breaker operates at 120 volts AC and features a bolt-on connection with a status switch for remote monitoring. Built for commercial and industrial applications, it combines thermal-magnetic protection and remote operation for efficient circuit management.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton Cutler-Hammer |
| Category |
Circuit Protection |
| Part Number |
BABRSP1030 |
| Subcategory |
Molded Case Circuit Breaker |
| Series |
Quicklag BABRS |
| Amperage Rating |
30A |
| Voltage Rating |
120 VAC |
| Number of Poles |
1 |
| Phase |
Single-Phase |
| Connection Type |
Bolt-On |
| Protection Type |
Thermal Magnetic |
| Trip Function |
LI – Long-Time and Instantaneous |
| AIC Rating |
10 kA @ 120V |
| Special Feature |
Status Switch |
| Certifications |
UL 489, CSA Std. C22.2 |
| Mounting Type |
Panelboard (Bolt-On) |
| Temperature Rating |
40°C Continuous Current |
| Country of Origin |
United States |
| Dimensions (H x W x D) |
6.25" x 3.75" x 1.25" |
| Weight |
0.54 lb (0.243 kg) |
Information About BABRSP1030
The BABRSP1030 is part of Eaton’s Quicklag BABRS Series, known for its precision-engineered molded case design and dependable overload protection. It integrates LI (Long-Time and Instantaneous) trip functions for both long-term circuit safeguarding and immediate short-circuit interruption. Designed for bolt-on installation, it is compatible with standard Eaton and Cutler-Hammer panelboards. The breaker’s remote operation capability and status switch make it suitable for applications requiring monitoring and control in electrical distribution systems.
Key Features
- Current Rating: 30 Amps – Provides dependable circuit protection for moderate load applications.
- Voltage Rating: 120 VAC – Optimized for low-voltage single-phase power systems.
- Connection Type: Bolt-On – Ensures secure and stable mounting in compatible panelboards.
- Trip Function: LI (Long-Time and Instantaneous) – Protects against both overloads and short circuits.
- Protection Type: Thermal Magnetic – Combines thermal and magnetic trip mechanisms for precise performance.
- Status Switch: Included – Allows remote status indication and system monitoring.
- Certifications: UL 489 and CSA C22.2 Approved – Meets international safety and reliability standards.
- Operating Temperature: Rated for 40°C Continuous Current – Ensures consistent operation under standard ambient conditions.
The BABRSP1030 delivers the reliability and precision required for safe and efficient power distribution in commercial and industrial electrical systems.
