Description
The Automation Direct T1F-16DA-1 Terminator analog output module is a 16-channel current output module designed for precise signal control in industrial automation systems. It delivers 12-bit resolution output supporting both 0–20 mA and 4–20 mA signal ranges. This module is ideal for applications requiring accurate analog control and integration with Terminator I/O platforms.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Automation Direct Terminator |
| Category |
Industrial Automation |
| Part Number |
T1F-16DA-1 |
| Subcategory |
Analog Output Modules |
| Module Type |
Analog Output |
| Number of Channels |
16 |
| Output Signal Type |
Current |
| Output Range |
0–20 mA, 4–20 mA |
| Output Resolution |
12-bit |
| Output Type |
Sinking |
| Isolated Channels |
No |
| Output Commons |
1 non-isolated common |
| External Power Requirement |
24 VDC |
| Compatible Terminal Bases |
T1K-16B, T1K-16B-1 |
| Programming Software |
Do-more Designer v1.2 or later |
| Series |
Terminator |
| Weight |
0.8 lb (approx.) |
Information About T1F-16DA-1
The T1F-16DA-1 is part of the Terminator series, engineered for modular and cost-effective distributed I/O solutions. It is designed to provide multiple analog current outputs using a sinking configuration, making it suitable for a wide range of process control applications. The module requires an external 24 VDC power supply and must be installed on a compatible T1K-16B or T1K-16B-1 terminal base for proper operation. It integrates with Do-more Designer programming software, allowing configuration and control within automated systems.
Key Features:
- 16 Analog Output Channels: Provides high-density output capability for multi-signal control applications
- Current Output Support: Delivers 0–20 mA and 4–20 mA signals for industrial devices
- 12-Bit Resolution: Ensures accurate and stable analog signal output
- Sinking Output Type: Suitable for common industrial control wiring configurations
- External Power Requirement: Operates with a 24 VDC external supply for reliable performance
- Terminator Series Compatibility: Designed for use with Terminator I/O systems
- Flexible Integration: Works with Do-more Designer software for configuration and control
- Terminal Base Requirement: Requires T1K-16B or T1K-16B-1 base for installation
The T1F-16DA-1 delivers the reliability and precision required for analog signal output and process control applications.
