Description
Tech Specs
Chassis:
- Front Flex Bay 1U - 12 x 2.5" SATA/SAS/NMVe
Processor types:
- 2 x Intel Xeon 4th Gen Scalable
- 2 x Intel Xeon 5th Gen Scalable
- Up to 64 Cores / 128 Threads per Processor
- Socket: Intel Socket 4677
Memory RAM types:
- 32 Slots, 2 channels
- 2 channels 2 slots per channel
- Max configuration: 4TB DDR5 4800 MT/s - 4th Gen Scalable CPU
32 x 128GB ECC Registered - Max configuration: 4TB DDR5 5600 MT/s - 5th Gen Scalable CPU
32 x 128GB ECC Registered
Storage Options 2.5" Drives
2 x M.2 Gen4
- NVMe M.2: up to 4TB
- SAS SSDs: 15.36TB @ 12GB/s
- SAS SSDs: 15.36TB @ 24GB/s
- SATA SSD: 15.36TB @ 6GB/s
- NVMe U.2: 15.36TB
Operating Systems:
- Windows Server 2022
- Windows Server 2019
- Ubuntu 22.04 LTS
- SuSE Linux Enterprise
- RHEL 9.x
- CentOS
- VMware
Power Supplies:
- 1+1 Redundant 1200W 80 PLUS Platinum
- 1+1 Redundant 1200W 80 PLUS Titanium
- 1+1 Redundant 1600W 80 PLUS Platinum
- 1+1 Redundant 1600W 80 PLUS Titanium
Storage Controllers RAID Options:
- Broadcom MegaRAID 9560-16i
- Broadcom MegaRAID 9670W-16i
- Broadcom MegaRAID 9540-8i
- Broadcom HBA 9500-16i
- Graid SupremeRaid SR1000 GPU cards
Network Interface Card Options (NICs) PCIe and OCP 3.0
- Intel E810-CQDA
- Broadcom N2100G
- NVIDIA Mellanox ConnectX-6 DX
- NVIDIA Mellanox ConnectX-6 LX
- Intel X710-T2L
- Intel E810-XXVDA
Expansion Slots:
- 1 x PCIe Gen5 x16 (FHFL)
- 1 x PCIe Gen5 x16 or 1 x OCP3.0 (FHFL)
- 1 x PCIe Gen5 x16 (LP)
- 1 x PCIe Gen4 x8 (LP, internal)
ASUS RS700-E11-RS12U Supported CPUs
| Intel Xeon 4th Gen Scalable | Cores/Threads | Frequency | Turbo Frequency |
|---|---|---|---|
| Intel Xeon Bronze 3408U | 8C/8T | 1.80GHz | 1.90GHz |
| Intel Xeon Silver 4410T | 10C/20T | 2.70GHz | 4.00GHz |
| Intel Xeon Silver 4410Y | 12C/24T | 2.00GHz | 3.90GHz |
| Intel Xeon Silver 4416+ | 20C/40T | 2.00GHz | 3.90GHz |
| Intel Xeon Gold 5403N | 12C/24T | 2.00GHz | 3.90GHz |
| Intel Xeon Gold 5411N | 24C/48T | 1.90GHz | 3.90GHz |
| Intel Xeon Gold 5412U | 24C/48T | 2.10GHz | 3.90GHz |
| Intel Xeon Gold 5415+ | 8C/16T | 2.90GHz | 4.10GHz |
| Intel Xeon Gold 5416S | 16C/32T | 2.00GHz | 4.00GHz |
| Intel Xeon Gold 5418N | 24C/48T | 1.80GHz | 3.80GHz |
| Intel Xeon Gold 5418Y | 24C/48T | 2.00GHz | 3.80GHz |
| Intel Xeon Gold 5420+ | 28C/56T | 2.00GHz | 4.10GHz |
| Intel Xeon Gold 5423N | 20C/40T | 2.10GHz | 4.10GHz |
| Intel Xeon Gold 5433N | 20C/40T | 2.10GHz | 4.10GHz |
| Intel Xeon Gold 6403N | 24C/48T | 1.90GHz | 3.960GHz |
| Intel Xeon Gold 6414U | 32C/64T | 2.00GHz | 3.40GHz |
| Intel Xeon Gold 6416H | 18C/36T | 2.20GHz | 4.20GHz |
| Intel Xeon Gold 6418H | 24C/48T | 2.10GHz | 4.00GHz |
| Intel Xeon Gold 6421N | 32C/64T | 1.80GHz | 3.60GHz |
| Intel Xeon Gold 6423N | 28C/56T | 2.00GHz | 3.60GHz |
| Intel Xeon Gold 6426Y | 16C/32T | 2.50GHz | 4.10GHz |
| Intel Xeon Gold 6428N | 32C/64T | 1.80GHz | 3.80GHz |
| Intel Xeon Gold 6430 | 32C/64T | 2.10GHz | 3.40GHz |
| Intel Xeon Gold 6433N | 32C/64T | 2.00GHz | 3.60GHz |
| Intel Xeon Gold 6433NE | 32C/64T | 2.00GHz | 3.60GHz |
| Intel Xeon Gold 6434 | 8C/16T | 3.70GHz | 4.10GHz |
| Intel Xeon Gold 6434H | 8C/16T | 3.70GHz | 4.10GHz |
| Intel Xeon Gold 6438M | 32C/64T | 2.20GHz | 3.90GHz |
| Intel Xeon Gold 6438N | 32C/64T | 2.00GHz | 3.60GHz |
| Intel Xeon Gold 6438Y+ | 32C/64T | 2.00GHz | 4.00GHz |
| Intel Xeon Gold 6442Y | 24C/48T | 2.60GHz | 4.00GHz |
| Intel Xeon Gold 6443N | 32C/64T | 2.00GHz | 3.60GHz |
| Intel Xeon Gold 6444Y | 16C/32T | 3.60GHz | 4.00GHz |
| Intel Xeon Gold 6448H | 32C/64T | 2.40GHz | 4.10GHz |
| Intel Xeon Gold 6448Y | 32C/64T | 2.10GHz | 3.40GHz |
| Intel Xeon Gold 6454S | 32C/64T | 2.20GHz | 3.40GHz |
| Intel Xeon Gold 6458Q | 32C/64T | 3.10GHz | 4.00GHz |
| Intel Xeon Platinum 8444H | 16C/32T | 2.90GHz | 4.00GHz |
| Intel Xeon Platinum 8450H | 28C/56T | 2.00GHz | 3.50GHz |
| Intel Xeon Platinum 8452Y | 36C/72T | 2.00GHz | 3.20GHz |
| Intel Xeon Platinum 8454H | 32C/64T | 2.10GHz | 3.40GHz |
| Intel Xeon Platinum 8458P | 44C/88T | 2.70GHz | 3.80GHz |
| Intel Xeon Platinum 8460H | 40C/80T | 2.20GHz | 3.80GHz |
| Intel Xeon Platinum 8460Y+ | 40C/80T | 2.00GHz | 3.70GHz |
| Intel Xeon Platinum 8461V | 48C/96T | 2.20GHz | 3.70GHz |
| Intel Xeon Platinum 8462Y+ | 32C/64T | 2.80GHz | 4.10GHz |
| Intel Xeon Platinum 8468 | 48C/96T | 2.10GHz | 3.80GHz |
| Intel Xeon Platinum 8468H | 48C/96T | 2.10GHz | 3.80GHz |
| Intel Xeon Platinum 8468V | 48C/96T | 2.40GHz | 3.80GHz |
| Intel Xeon Platinum 8470 | 52C/104T | 2.00GHz | 3.80GHz |
| Intel Xeon Platinum 8470N | 52C/104T | 1.70GHz | 3.60GHz |
| Intel Xeon Platinum 8470Q | 52C/104T | 2.10GHz | 3.80GHz |
| Intel Xeon Platinum 8471N | 52C/104T | 1.80GHz | 3.60GHz |
| Intel Xeon Platinum 8480+ | 56C/112T | 2.00GHz | 3.80GHz |
| Intel Xeon Platinum 8490H | 60C/120T | 1.90GHz | 3.50GHz |
| Intel Xeon 5th Gen Scalable | Cores/Threads | Frequency | Turbo Frequency |
|---|---|---|---|
| Intel Xeon Bronze 3508U | 8C/8T | 2.10GHz | 2.20GHz |
| Intel Xeon Silver 4509Y | 8C/16T | 2.60GHz | 4.10GHz |
| Intel Xeon Silver 4510 | 12C/24T | 2.40GHz | 4.10GHz |
| Intel Xeon Silver 4510T | 12C/24T | 2.00GHz | 3.70GHz |
| Intel Xeon Silver 4514Y | 16C/32T | 2.00GHz | 3.40GHz |
| Intel Xeon Silver 4516Y+ | 24C/48T | 2.20GHz | 3.70GHz |
| Intel Xeon Gold 5512U | 28C/56T | 2.10GHz | 3.70GHz |
| Intel Xeon Gold 5515+ | 8C/16T | 3.20GHz | 4.10GHz |
| Intel Xeon Gold 5520+ | 28C/56T | 2.20GHz | 4.00GHz |
| Intel Xeon Gold 6526Y | 16C/32T | 2.80GHz | 3.90GHz |
| Intel Xeon Gold 6530 | 32C/64T | 2.10GHz | 4.00GHz |
| Intel Xeon Gold 6534 | 8C/16T | 3.90GHz | 4.20GHz |
| Intel Xeon Gold 6538N | 32C/64T | 2.10GHz | 4.10GHz |
| Intel Xeon Gold 6538Y+ | 32C/64T | 3.90GHz | 4.20GHz |
| Intel Xeon Gold 6542Y | 24C/48T | 2.90GHz | 4.10GHz |
| Intel Xeon Gold 6544Y | 16C/32T | 3.60GHz | 4.10GHz |
| Intel Xeon Gold 6548N | 32C/64T | 2.80GHz | 4.10GHz |
| Intel Xeon Gold 6548Y+ | 32C/64T | 2.50GHz | 4.10GHz |
| Intel Xeon Gold 6554S | 36C/72T | 2.20GHz | 4.00GHz |
| Intel Xeon Gold 6558Q | 32C/64T | 3.20GHz | 4.10GHz |
| Intel Xeon Platinum 8558 | 48C/96T | 2.10GHz | 4.00GHz |
| Intel Xeon Platinum 8558P | 48C/96T | 2.70GHz | 4.00GHz |
| Intel Xeon Platinum 8558U | 48C/96T | 2.00GHz | 4.00GHz |
| Intel Xeon Platinum 8562Y+ | 32C/64T | 2.80GHz | 4.10GHz |
| Intel Xeon Platinum 8568Y+ | 48C/96T | 2.30GHz | 4.00GHz |
| Intel Xeon Platinum 8570 | 56C/112T | 2.10GHz | 4.00GHz |
| Intel Xeon Platinum 8571N | 52C/104T | 2.40GHz | 4.00GHz |
| Intel Xeon Platinum 8580 | 60C/120T | 2.00GHz | 4.00GHz |
| Intel Xeon Platinum 8581V | 60C/120T | 2.00GHz | 3.90GHz |
| Intel Xeon Platinum 8592+ | 64C/128T | 1.90GHz | 3.90GHz |
| Intel Xeon Platinum 8592V | 64C/128T | 1.90GHz | 3.90GHz |
| Intel Xeon Platinum 8593Q | 64C/128T | 2.20GHz | 3.90GHz |
ASUS RS700-E11-RS12U RAID Options
| RAID Options | RAID Levels | Cache | Drive Speeds | PCIe Generation | RAID Hardware |
|---|---|---|---|---|---|
| Broadcom MegaRAID 9570W-16i | 0, 1, 5, 6, 10, 50, 60 | 8GB | 22Gb/s, 12Gb/s SAS | 16GT/s NVMe | 4.0 | Yes |
| Broadcom MegaRAID 9560-16i | 0, 00, 1, 10, 5, 6, 60 | 8GB | 12Gb/s SAS | 16GT/s NVMe | 4.0 | Yes |
| Broadcom MegaRAID 9540-8i | 0, 00, 1, 10 | N/A | 12Gb/s SAS | 16GT/s NVMe | 4.0 | Yes |
| Broadcom HBA 9500-16i | N/A | N/A | 12Gb/s SAS | 16GT/s NVMe | 4.0 | Yes |
