ASA 5516 Next-Generation Firewalls Overview

The Cisco ASA5516-FPWR-K9 is part of the ASA 5500-X series, equipped with FirePOWER services. It offers 8 Gigabit Ethernet data ports and 1 Gigabit Ethernet management port, supporting AC power and 3DES/AES VPN encryption. With a maximum stateful inspection throughput of 1.8 Gbps and 900 Mbps multiprotocol throughput, it provides excellent performance for enterprise security. The device can handle 850 Mbps application control throughput (AVC) and 450 Mbps with IPS. It supports unlimited users/nodes, making it ideal for scalable network protection. Shop Cisco Firewalls for the Cisco ASA5500-X Firewall and enhance your network with the advanced capabilities of the ASA5516-FPWR-K9, offering next-generation FirePOWER services for robust security.

Compare with similar items

Models	ASA5516-FPWR-K9	ASA5516-FPWR-K8
Product Description	ASA 5516-X with FirePOWER services, 8GE Data, 1GE Mgmt, AC, 3DES/AES	ASA 5516-X with FirePOWER services, 8GE Data, 1GE Mgmt, AC, DES
Stateful Inspection Throughput (multiprotocol)	850 Mbps	850 Mbps
Maximum 3DES/AES VPN Throughput	450 Mbps	450 Mbps
Memory	8GB	8GB
Flash	8GB	8GB
Height (rack units)	1 RU	1 RU



Specification

ASA5516-FPWR-K9 Specification
Product Number	ASA5516-FPWR-K9
Throughput:Application Control (AVC)	850 Mbps
Throughput:Application Control (AVC) and IPS	450 Mbps
Maximum concurrent sessions	250,000
Maximum New Connections per second	20,000
Supported applications	More than 3,000
URL categories	80+
Number of URLs categorized	More than 280 million
Centralized configuration, logging, monitoring, and reporting	Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center
On-Device Management	ASDM (version 7.3 or higher required)
Feature	Cisco ASA 5516-X w/ FirePOWER Services
Stateful inspection throughput (maximum)	1.8 Gbps
Stateful inspection throughput (multiprotocol)	900 Mbps
Triple Data Encryption Standard/ Advanced Encryption Standard (3DES/AES) VPN throughput	250 Mbps
Users/nodes	Unlimited
IPsec site-to-site VPN peers	300
Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections	300
Virtual interfaces (VLANs)	100
Security contexts(included; maximum)	2; 5
High availability	Active/Active and Active/Standby
Integrated Wireless Access Point (See Cisco AP 702 datasheet for WiFi technical details)	N/A
Expansion slot	N/A
User-accessible Flash slot	No
USB 2.0 ports	USB port type ‘A’, High Speed 2.0
Integrated I/O	8 x 1 Gigabit Ethernet (GE)
Expansion I/O	N/A
Dedicated management port	Yes (To be shared with FirePOWER Services), 10/100/1000
Serial ports	1 RJ-45 and Mini USB console
Solid-state drive	100 GB mSata
Memory	8 GB
System flash	8 GB
System bus	Multibus architecture
Temperature	32 to 104°F (0 to 40 °C)
Relative humidity	10 to 90 percent noncondensing
Altitude	Designed and tested for 0 to 10,000 ft (3048 m)
Acoustic noise	41.6 dBA type
Temperature	-13 to 158ºF (-25 to 70ºC)
Relative humidity	10 to 90 percent noncondensing
Altitude	Designed and tested for 0 to 15,000 ft (4572 m)
AC range line voltage	External, 90 to 240 volts alternating current (VAC)
AC normal line voltage	90 to 240 VAC
AC current	0.25AC amps
AC frequency	50/60 Hz
Dual-power supplies	None
DC domestic line voltage	N/A
DC international line voltage	N/A
DC current	N/A
Steady state	12V @ 3.0A
Maximum peak	12V @ 5.0A
Maximum heat dissipation	205 Btu/hr
Form factor	1 rack unit (RU), 19-in. rack-mountable
Dimensions(H x W x D)	1.72 x 17.2 x 11.288 in.
Weight (with AC power supply)	8 lb (3 kg)
