Description
The FANUC A06B-6090-H234 is a dual-axis servo amplifier designed for CNC motion control systems. It operates on 200–230 VAC, three-phase input power and provides rated output current up to 11 A. Engineered for precision axis control, it integrates protection and air-cooled performance for industrial automation environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
FANUC |
| Category |
Servo Products |
| Part Number |
A06B-6090-H234 |
| Subcategory |
Servo Drive/Servo Control |
| Product Type |
Servo Amplifier |
| Number of Axes |
2 |
| Series |
Alpha (SVUC2-12/40) |
| Input Voltage |
200–230 VAC |
| Input Phase |
3 Phase |
| Frequency |
50/60 Hz |
| Rated Output Current |
11 A |
| Cooling Method |
Air Cooled |
| Operating Temperature |
0°C to 55°C |
| Protection Features |
Overload, Overcurrent, Overvoltage |
| Mounting |
Vertical/Wall-mounted |
| Weight |
14.05 lbs |
Information About A06B-6090-H234
The A06B-6090-H234 belongs to the FANUC Alpha series servo amplifier lineup and is identified as the SVUC2-12/40 dual-axis servo unit. It is designed to control two servo axes within CNC machinery and automated manufacturing systems. The amplifier supports 50/60 Hz power systems and incorporates protection features against overload, overcurrent, and overvoltage conditions. Built for vertical or wall-mounted installation, it operates within a temperature range of 0°C to 55°C and uses air cooling to maintain stable performance.
Key Features:
-
Dual-Axis Control: Drives and manages two servo motor axes simultaneously.
-
200–230 VAC Input: Designed for industrial three-phase power systems.
-
11 A Rated Output Current: Supports precision CNC motion requirements.
-
Alpha Series SVUC2-12/40: Identified as a dual-axis servo amplifier module.
-
Integrated Protection: Includes overload, overcurrent, and overvoltage safeguards.
-
Air-Cooled Design: Maintains thermal stability during operation.
-
50/60 Hz Compatibility: Suitable for global power standards.
-
Flexible Mounting: Supports vertical or wall-mounted installation.
The A06B-6090-H234 delivers the reliability and precision required for CNC servo drive and dual-axis motion control applications.
