Description
The Cognex 821-0101-1R is a rugged handheld barcode scanner built for demanding industrial environments. It delivers high-performance decoding of both 1D and 2D barcodes and operates reliably even with damaged or low-contrast codes.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Cognex |
| Category |
|
| Part Number |
821-0101-1R
|
| Subcategory |
Bar Code Scanner Hand Held |
| Series |
DataMan 8050X |
| Alternate Part Numbers |
DMR-8050X-0200, 825-0489-1R |
| Device Type |
Handheld Barcode Scanner |
| Supported Codes |
1D and 2D symbologies |
| Power Supply |
5V to 6V DC |
| Max Current |
500 mA |
| Battery Included |
Yes (Part # 820-0041-1R) |
| Connectivity |
USB or wireless (depends on configuration) |
| Dimensions (LxWxH) |
7.09 x 6.3 x 8.27 inches |
| Operating Mode |
Cordless, battery-powered |
| Environmental Sealing |
Industrial-grade (exact IP rating varies by version) |
| Operating Temperature |
0°C to 45°C |
| Mounting/Use |
Handheld |
| Weight |
1.00 lbs |
Information About 821-0101-1R
The 821-0101-1R belongs to the Cognex DataMan 8050X series and corresponds to model number DMR-8050X-0200. This scanner is designed to provide fast, accurate barcode reading and is ideal for use in manufacturing, logistics, and warehouse operations. The unit is powered by a 5V–6VDC source and draws up to 500 mA, making it compatible with mobile setups. It includes a rechargeable battery (part number 820-0041-1R) and is ergonomically designed for comfortable use throughout the workday.
Key Features:
- High-Speed Decoding: Reads both 1D and 2D barcodes with precision, including damaged or obscured codes.
- Rugged Construction: Designed for industrial use, withstanding drops and exposure to harsh conditions.
- Battery Operated: Comes with a rechargeable battery for mobile and cordless operation.
- Ergonomic Design: Balanced and contoured for extended handheld use without fatigue.
- Flexible Power Input: Operates on 5–6 VDC with a maximum current draw of 500 mA.
- Compact Dimensions: Sized for practical deployment, with minimal space requirements.
- Plug-and-Play Use: Supports quick integration into scanning systems without complex setup.
- Multi-Code Compatibility: Supports reading of a wide variety of 1D/2D symbologies.
The 821-0101-1R delivers the reliability and flexibility needed for demanding barcode scanning operations in industrial and logistics environments.
