Description
The Allen-Bradley 800T-U13 is a high-quality 30 mm potentiometer unit designed for reliable manual control of electrical signals in industrial automation environments. With a 1000-ohm resistive element and a rugged build, it is suitable for both AC and DC voltage applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
800T-U13
|
| Subcategory |
Potentiometer |
| Series |
|
| Resistance |
1000 Ohm |
| Voltage Rating |
300 VAC/DC |
| Wattage Rating |
2 Watts (Min. 6 VDC) |
| Size |
30 mm Operator |
| Terminal Protection |
No Finger-Safe Guards |
| Enclosure Type |
Type 4/13 |
| Standards Compliance |
CCC, CE, CSA, CUL, KC, MARINE, UL |
| Weight |
0.3300 lb |
Information About 800T-U13
The 800T-U13 is part of the trusted 800T series, engineered for robust panel control applications. This unit features a 30 mm diameter and a 1000 Ω resistance value, optimized for manual signal variation in control circuits. It operates with a maximum voltage of 300 VAC/DC and a power handling capacity of 2 watts, with a minimum voltage requirement of 6 VDC for optimal performance. It does not include finger-safe terminal guards, making it suitable for enclosed environments or installations with added safety precautions.
Key Features:
- Precision Resistance Control: Equipped with a 1000 ohm resistive element, the unit provides fine manual adjustment of voltage or current within a circuit.
- Durable and Compact Build: The 30 mm operator size ensures a compact fit for control panels while maintaining durability for heavy-duty use.
- High Voltage Tolerance: Rated for operation up to 300 VAC or DC, offering flexibility for diverse control applications.
- 2-Watt Power Rating: Suitable for signal-level applications with reliable thermal performance at moderate loads.
- Global Standards Compliance: Certified under multiple international safety and performance standards, making it applicable for use in marine, industrial, and hazardous environments.
The 800T-U13 delivers precise signal modulation in a compact footprint, engineered to meet the demands of industrial control systems.
