Description

The Allen-Bradley 800T-QTH2R is a rugged pilot light designed for industrial control panels, featuring an LED illumination source for reliable and energy-efficient status indication. With a red lens and push-to-test functionality, it is ideal for critical visual signaling applications.

Technical Specifications

Information About 800T-QTH2R

The 800T-QTH2R belongs to the Allen-Bradley 800T series, known for its durability and adaptability in demanding industrial environments. This 30.5mm pilot light features a Type 4/13 metal enclosure with an IP65 rating, providing protection against dust, water, and harsh conditions. It utilizes an LED lamp rated for operation between 12-130 VAC/DC, ensuring long service life and reduced maintenance. The unit is designed with a round/flat red lens for clear visibility. Additionally, it includes a push-to-test option, allowing operators to verify lamp operation without disrupting the circuit.

Key Features:

• LED Illumination: Provides bright, energy-efficient status indication with long lifespan.
• Wide Voltage Range: Operates between 12-130 VAC/DC, accommodating diverse control systems.
• Push-to-Test Function: Allows operators to verify lamp operation during maintenance or checks.
• Red Lens Color: Offers high visibility for critical status signaling.
• IP65 Rated: Resistant to dust and water ingress for use in harsh environments.
• 30.5mm Mounting Diameter: Standard size for industrial control panels.
• Screw Terminals: Ensures secure and reliable electrical connections.
• Metal Type 4/13 Enclosure: Provides durability and mechanical protection.
• Flexible Contact Configuration: Supports 1 NO/1 NC contacts for versatile control applications.
• Global Certification: Meets CCC, CE, CSA, CUL, KC, Marine, and UL standards.

The 800T-QTH2R offers reliable, durable, and versatile status indication for industrial control systems.
