Description
The 800T-FXMP16RA7 is an Allen-Bradley push-pull operator from the 800T series, designed for rugged industrial control applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
800T-FXMP16RA7 |
| Subcatecory |
|
| Actuator |
3-Position Maintained In |
| Contact Configuration |
1 NO, 1 NC |
| Illumination Type |
Incandescent |
| Lens Color |
Red |
| Operator Type |
Standard Mushroom Cap |
| Standard |
CCC,CE,CSA,CUL,KC,MARINE,UL |
| Voltage |
120 Volt |
| Block Type |
Standard |
| Head Type |
Standard Size Mushroon Head (40mm) |
| Lamp Voltage |
120 V |
| Lens Type |
Round |
| Split Crucible |
S |
| Protection Rating |
Metal, Type 4/13 |
| Weight |
0.40 lbs |
Information About 800T-FXMP16RA7
The 800T-FXMP16RA7 is a rugged push-pull operator from Allen-Bradley’s 800T series, engineered for reliable performance in industrial control applications requiring maintained action and high durability.
Key Features:
- Type: Push-Pull Operator
- Series: 800T
- Head Type: Mushroom head, red
- Action: Maintained push-pull (stays in position when operated)
- Contact Configuration: 1 Normally Open (1 NO) and 1 Normally Closed (1 NC) contact
- Operating Voltage: 120V AC
- Mounting Size: 30 mm
- Construction: Heavy-duty metal design for durability
- Enclosure Rating: Type 4/13 (resistant to water, dust, and oil; suitable for industrial environments)
- Certifications: UL, CSA, CE
- Applications: Ideal for emergency stop and control applications in machinery, conveyors, and other industrial automation systems where clear, maintained control is required
The 800T-FXMP16RA7 offers robust construction and reliable maintained-action control, making it suitable for demanding industrial applications requiring secure and visible operator interface.
