Description
The Pilz 750134 PNOZ s4 is a compact safety relay from the PNOZsigma series designed for reliable monitoring of emergency stop circuits and safety gates. Operating on a wide 48–240 VAC/DC supply range, it provides multiple safety outputs in a narrow housing for space-efficient safety control.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Pilz |
| Category |
Safety Relays |
| Part Number |
750134 |
| Subcategory |
Safety Relays |
| Series |
PNOZsigma |
| Model |
PNOZ s4 |
| Supply Voltage |
48…240 VAC/DC |
| Type of Supply Voltage |
AC/DC |
| Power Consumption (AC) |
5 VA |
| Power Consumption (DC) |
2.5 W |
| Input Configuration |
1- or 2-channel wiring, with/without cross-short detection |
| Safety Outputs |
3 × N/O, 1 × N/C |
| Semiconductor Output |
1 (UB) |
| Application |
Emergency stop, safety gate monitoring |
| Electrical Connection |
Plug-in screw terminals |
| Conductor Size |
24…12 AWG |
| Ambient Temperature |
-10…55°C |
| Humidity Rating |
93% RH at 40°C |
| Dimensions (W×H×D) |
22.5 × 98 × 120 mm |
| Weight |
0.46 lb (210 g) |
Information About 750134
The 750134 is part of the Pilz PNOZsigma safety relay family, developed to combine compact design with advanced safety functionality. It supports both single- and dual-channel safety circuits, allowing flexible integration into different machine safety architectures. The relay provides multiple safety contacts and a semiconductor output, enabling reliable control and signaling in safety-related applications. Its wide AC/DC supply range and narrow 22.5 mm housing make it suitable for modern control panels where space efficiency and versatility are critical.
Key Features
- PNOZsigma Safety Relay Platform: Delivers advanced safety functionality in an ultra-slim 22.5 mm housing for space-saving installations.
- Wide Supply Voltage Range: Operates on 48 to 240 VAC/DC, simplifying power supply design across different systems.
- Flexible Input Configuration: Supports 1- or 2-channel wiring with optional cross-short detection for adaptable safety circuit design.
- Multiple Safety Outputs: Includes three normally open and one normally closed safety contacts for versatile control integration.
- Integrated Semiconductor Output: Provides additional signaling or control capability using the UB output.
- Plug-In Screw Terminals: Enable fast installation, secure wiring, and simplified maintenance.
- Designed for Safety Monitoring: Suitable for emergency stop circuits and safety gate applications in industrial machinery.
The 750134 delivers the reliability and precision required for compact, efficient safety monitoring in industrial automation environments.
