The Allen-Bradley 700-FSM6UU23 is a high-performance, multi-function timing relay designed for precision time-delay control in automation systems. With a compact 22.5 mm DIN rail-mounted design, this versatile relay supports a wide voltage range and a wide array of timing functions, making it ideal for industrial timing applications in control panels and machinery.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Allen-Bradley
Category	Relays
Part Number	700-FSM6UU23
Subcatecory	Time Delay Relays
Voltage Range	24–240 VAC / 24–48 VDC
Input Current	1 mA
Contact Configuration	SPDT (1 CO)
Contact Rating	5 A
Dielectric Strength	4000 V
Operating Cycles (Mechanical)	30,000,000
Mounting Style	DIN Rail
Temperature Range	-25°C to 60°C
Weight	0.2900 lb





Information About 700-FSM6UU23

The 700-FSM6UU23 supports a universal input voltage range of 24–240 VAC and 24–48 VDC, allowing flexible installation in diverse control systems. It features a single-pole, double-throw (SPDT) or 1 CO (changeover) contact configuration with a contact rating of 5 A, supporting reliable switching for control loads. The relay operates at just 1 mA input, making it energy efficient, and provides 30 million mechanical operating cycles, ensuring long-term durability and performance.

Key Features:

• Multi-Function Timing Modes: Supports a variety of delay and pulse timing operations for versatile control applications.

• Wide Voltage Range: Operates with both AC (24–240V) and DC (24–48V) systems, increasing deployment flexibility.

• High Durability: Rated for up to 30 million mechanical cycles for long-term use in automation systems.

• Compact DIN Rail Design: Slim 22.5 mm housing saves panel space while ensuring quick and secure mounting.

• SPDT Output Configuration: Provides one changeover contact for flexible wiring in control circuits.

The 700-FSM6UU23 is ideal for use in industrial automation panels, HVAC systems, motor control applications, and sequential logic control setups.
