Description
The Allen-Bradley 700-FEA1TU22 is a general-purpose economy timing relay designed for on-delay timing functions in industrial control circuits. Its adjustable timing range and versatile voltage compatibility make it a practical solution for time-based automation requirements.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
700-FEA1TU22
|
| Subcategory |
Time Delay Relay |
| Series |
700-FE |
| Timing Function |
On-Delay |
| Timing Range |
0.05 seconds to 10 hours |
| Contact Configuration |
1 N.O. |
| Voltage Rating |
24 V AC/DC, 110-240 V AC, 50/60 Hz |
| Contact Rating |
5 Amps |
| Mounting Type |
DIN Rail |
| Coil Surge Protection |
Yes |
| Standards Compliance |
Industrial Quality Standards |
| Weight |
0.05 lbs |
Information About 700-FEA1TU22
The 700-FEA1TU22 is part of the Allen-Bradley 700-FE series economy timing relays, providing an on-delay function with an adjustable timing range from 0.05 seconds to 10 hours. It operates with a single normally open (N.O.) contact, offering straightforward integration into control circuits requiring timed actuation. This model supports a dual voltage range of 24 V AC/DC and 110-240 V AC at 50/60 Hz, ensuring compatibility with a wide variety of industrial power systems.
Key Features:
- On-Delay Timing Function: Provides reliable delay-on activation with adjustable timing.
- Wide Timing Range: Adjustable from 0.05 seconds to 10 hours to suit diverse applications.
- Versatile Voltage Compatibility: Operates at 24 V AC/DC or 110-240 V AC, 50/60 Hz.
- Single Normally Open Contact: Supports straightforward integration into control logic circuits.
- Coil Surge Protection: Extends the life of the relay by reducing voltage spikes.
- 5 Amp Contact Rating: Handles moderate load switching with dependable performance.
- DIN Rail Mounting: Allows for quick and easy installation into industrial control panels.
- Compact Design: Saves space while maintaining functionality for time-based automation.
- Standard Compliance: Designed to meet international industrial control standards.
- Legacy Support: Still available for system maintenance and replacement in existing installations.
The 700-FEA1TU22 offers versatile timing control in a compact, reliable package, ideal for standard automation applications.
