Description
The Allen-Bradley 700-CF310E is a high-performance industrial control relay designed for low-level switching applications. Featuring a 380 V control coil and durable silver contacts, it supports dependable operation in both AC and DC control circuits.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
700-CF310E |
| Subcatecory |
|
| Amperage |
20 Amp |
| Coil Voltage |
380 V |
| Connection Type |
Screw Terminals |
|
Contact Material
|
Silver |
| Number of Poles |
4 Pole |
| Standard |
CCC,KC |
| Temperature Rating |
-25 to 60 degrees C |
| Conductor Size |
16-10 AWG |
| Contact Configuration |
3 NO, 1 NC |
| Voltage |
115-690 VAC |
| Weight |
0.8400 lb |
Information About 700-CF310E
The 700-CF310E is part of the MCS-CF series of control relays and includes a 4-pole configuration with 3 normally open and 1 normally closed contact arrangement. Rated at 20 Amps, it is designed to operate within a voltage range of 115–690 VAC and provides high mechanical durability across 1.2 million electrical cycles. The relay uses a 380 V coil voltage and screw-type terminals for secure and straightforward wiring. With certifications including CCC and KC, it is engineered for reliable performance in globally deployed industrial control systems.
Key Features:
- 4-Pole Contact Configuration: includes 3 NO and 1 NC silver contacts for flexible circuit design and control.
- High Endurance: supports up to 1,200,000 electrical operating cycles for long-term reliability.
- 380 V Coil Voltage: operates on high-voltage AC control systems while maintaining stable performance.
- Secure Connections: screw terminals accommodate 16–10 AWG conductors for firm and consistent wiring.
- Wide Voltage Range: supports switching operations across 115–690 VAC for global industrial compatibility.
- Certified Performance: meets CCC and KC standards for safety and compliance in regulated environments.
The 700-CF310E delivers a compact and durable solution for control applications requiring reliable switching, long service life, and robust electrical performance.
