Description

The 40FR4042 is a DC regenerative drive from the Reliance Electric FlexPak 3000 series designed for precise motor control in demanding industrial environments. It delivers 40 horsepower at 460V and supports up to 63 amps of current for high-performance applications.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Reliance Electric
Category	Drives
Part Number	40FR4042
Subcatecory	Motor Drives
Series	FlexPak 3000
Drive Type	DC Regenerative Drive
Horsepower Rating	40 HP
Voltage	460V AC Input
Max Current	63 Amps
Mounting	Panel Mount
Dimensions (W x H x D)	10.65 x 18.79 x 12.23 in
Shipping Weight	58 lbs





Information About 40FR4042

The 40FR4042 belongs to the FP3000 line of DC drives known for their reliability and flexibility in motor speed control. With regenerative capabilities, it allows energy to be fed back into the power supply during braking, increasing overall efficiency. This model supports a 40 HP motor and operates at 460 volts, making it suitable for a wide range of industrial machinery. Its compact design—10.65 inches in width, 18.79 inches in height, and 12.23 inches in depth—enables installation in space-constrained panels, while its 58-pound weight reflects its robust construction. Up to three drives can be operated on the same transformer without performance loss.

Key Features:

• DC Regenerative Operation: Enables energy recovery during braking for improved energy efficiency.

• High Power Output: Supports 40 HP motors at 460V with a maximum current of 63A.

• Compact Design: Space-efficient footprint with rugged build for industrial environments.

• Multiple Drive Integration: Allows up to three units per transformer for system scalability.

• FlexPak 3000 Series: Part of a trusted line known for motor control precision and reliability.

The 40FR4042 provides industrial users with reliable DC motor control, energy regeneration, and space-saving design.
