Description
The Omron 3F88M-DRT141 Axis Positioner is a precision motion control module designed for positioning and synchronization of servo or stepper motors in industrial automation systems. Operating as a DeviceNet-compatible positioning controller, it provides reliable, high-speed control for single-axis applications. The unit integrates seamlessly with Omron PLCs and servo systems to enable accurate motion sequencing, speed control, and coordinated positioning.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Motion Control Equipment |
| Part Number |
3F88M-DRT141 |
| Subcategory |
Axis Positioners |
| Series |
3F88M Series |
| Type |
DeviceNet Axis Positioner |
| Control Type |
Single-Axis Motion Control |
| Communication Interface |
DeviceNet |
| Compatible Systems |
Omron SYSMAC, PLC, and Servo Systems |
| Input Voltage |
24 VDC (typical) |
| Output Type |
Pulse Train (for Servo/Stepper Control) |
| Motion Modes |
Incremental, Absolute, Teaching, Continuous |
| Feedback Type |
Encoder or Limit Switch Input (depending on configuration) |
| Digital I/O |
Configurable for Home, Limit, and Control Signals |
| Maximum Output Frequency |
Model dependent (typ. up to 500 kHz) |
| Mounting Type |
DIN Rail |
| Termination |
Screw or Plug-in Terminals |
| Protection Rating |
IP20 (for control cabinet installation) |
| Operating Temperature |
0°C to 55°C |
| Application |
Positioning, Indexing, Conveyor Control, Robotics |
| Certifications |
CE, UL, cUL |
| Country of Origin |
Japan |
| Weight |
Approx. 0.7 lbs |
Information About 3F88M-DRT141
The 3F88M-DRT141 is part of the Omron 3F88M Series, a family of motion controllers designed to simplify axis control in distributed automation networks. This model operates as a DeviceNet-based positioner, allowing easy configuration, communication, and monitoring from a central PLC or control system. It supports a variety of motion profiles—such as incremental, absolute, and teaching modes—and provides flexible output control for servo or pulse-train-driven motors. Designed for compact installation, the 3F88M-DRT141 ensures smooth motion, quick response, and integration with Omron’s SYSMAC and DeviceNet systems for enhanced productivity in motion-intensive applications.
Key Features:
- DeviceNet Communication: Enables seamless integration with Omron PLCs and distributed control networks.
- Single-Axis Control: Provides precision motion control for servo or stepper motor applications.
- High-Speed Positioning: Delivers fast response and accurate pulse output for precise motion profiles.
- Multiple Control Modes: Supports absolute, incremental, and teaching positioning operations.
- Flexible I/O Interface: Offers digital inputs and outputs for limit switches, homing, and control signals.
- Compact DIN-Rail Mount Design: Saves space in control panels and simplifies installation.
- Parameter Setup and Monitoring: Configurable through Omron DeviceNet tools or PLC interface.
- Omron SYSMAC Compatibility: Integrates with Omron motion controllers and servo drives for synchronized automation.
The 3F88M-DRT141 delivers the reliability and precision required for single-axis motion control in machine automation, robotics, and material handling systems.
