Description
The Allen-Bradley 2098-DSD-HV050X-DN is an indexing Ultra 3000i servo drive designed for high-performance motion control applications. It supports DeviceNet communication and offers efficient conveyor control with smooth acceleration and deceleration.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
2098-DSD-HV050X-DN
|
| Subcatecory |
|
| Series |
Ultra 3000 Drives |
| Output Current (Intermittent) |
22 Amps (0-peak) |
| Output Current (Continuous) |
11 Amps (0-peak) |
| Auxiliary Power Supply |
Yes |
| Nominal Input Current (AC) |
7 Amps Root Means Square |
| Input Frequency (AC) |
47-63 Hz |
| Input Voltage (AC) |
230-480 Voltage Root Means Square (Three Phase) |
| Bus Overvoltage |
810 Volts dc |
| Shunt On |
800 Volts dc |
| Dimensions |
750 Volts dc |
| Weight |
9.54 x 14.2 x 5.46 in (242.2 x 360.7 x 138.7 mm) |
| Features |
DeviceNet and Indexing |
| Internal Shunt Resistance |
120 Ohms |
Information About 2098-DSD-HV050X-DN
The 2098-DSD-HV050X-DN is part of the Ultra 3000 Drive Series by Allen-Bradley. This servo drive enables precise indexing functionality and robust DeviceNet communication. With an intermittent output current of 22A and continuous operation at 11A, the drive is well-suited for demanding motor control tasks. It supports three-phase input voltages from 230 to 480 VAC and features built-in auxiliary power and internal shunt resistance for dynamic braking.
Key Features:
-
Indexing Capability: Built-in control for stepwise positioning in conveyor or linear actuator systems.
-
DeviceNet Interface: Integrates with Rockwell Automation systems for remote monitoring and control.
-
High Intermittent Output Current: Delivers up to 22 Amps peak for handling sudden load changes.
-
Three-Phase Voltage Input: Operates on a wide 230–480V AC input range for versatile installations.
-
Auxiliary Power Supply: Supports essential drive functions even when main input is off.
-
Integrated Dynamic Braking: Features 120 Ohm internal shunt resistance with shunt triggering at 800 VDC for motor deceleration.
-
Compact Design: Measures 9.54 x 14.2 x 5.46 inches for streamlined cabinet mounting.
The 2098-DSD-HV050X-DN is engineered to handle fast-paced industrial automation systems with precision, power, and network flexibility.
