Description
The Allen-Bradley 198E-AYTJ2 is a non-metallic IP65-rated enclosure designed for use with 140M-C motor protection circuit breakers. Featuring a robust plastic housing and an integrated red/yellow rotary handle, this enclosure is purpose-built for fixed-speed direct-on-line motor starting applications up to 25 amps.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
198E-AYTJ2
|
| Subcategory |
Enclosure |
| Enclosure Type |
Non-Metallic, Lift-off Cover
|
| Material |
ABS Plastic |
| Compatible Device |
140M-C Motor Circuit Breakers |
| Handle |
Red/Yellow, Rotary, Lockable |
| Max Current |
25 Amp |
| IP Rating |
IP65 |
| Mounting |
Surface |
| Cable Knockouts |
2 x M20/25 |
| Standards |
KC Certified |
| Depth |
100 mm |
| Width |
90.3 mm |
| Height |
162 mm |
| Weight |
0.8600 lb |
Information About 198E-AYTJ2
The 198E-AYTJ2 is part of Allen-Bradley’s 198E enclosure line and is specifically designed for compatibility with 140M-C motor circuit breakers. It supports direct-on-line motor starting and accommodates installations up to 25 A. Constructed from durable ABS plastic, the unit features a lift-off cover for straightforward access during installation or maintenance. Its design includes a red/yellow front-mounted handle for clear operational status and compliance with international motor disconnect standards.
Key Features:
- Compatible with 140M-C Circuit Breakers: Purpose-built for use with Allen-Bradley 140M-C series, ensuring perfect alignment and secure mounting of motor protection devices.
- Red/Yellow Rotary Handle: Clearly indicates operational status and meets global disconnect requirements for motor control panels, enhancing operator safety.
- IP65 Enclosure Rating: Provides strong resistance to dust and water, allowing safe operation in industrial settings including washdown areas.
- Lift-Off Cover Design: Simplifies access for wiring, device installation, or inspection, reducing maintenance time.
- Durable ABS Plastic Construction: Non-metallic housing resists corrosion and is suitable for harsh or chemically exposed environments.
- Lockable Handle Feature: Supports padlocking in the OFF position to comply with lockout/tagout (LOTO) procedures and prevent accidental energization.
- Pre-Configured Knockouts: Includes 2 M20/25 knockouts for flexible cable entry options without additional drilling.
- 25 Amp Maximum Current Support: Optimized for direct-on-line motor starting applications within small to medium load ranges.
The 198E-AYTJ2 enclosure offers rugged, standards-compliant protection with intuitive control features for motor protection applications in automation and process control.
