Description
The Allen-Bradley 1492-AIFM6S-3 is a 6-channel feed-through isolated analog interface module designed to provide secure and reliable connections for analog signal transmission. This module offers input-to-output isolation and accommodates both AC and DC signals, making it an effective choice for analog integration in industrial control systems.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
1492-AIFM6S-3
|
| Subcatecory |
|
| Channels |
6 (Feed-Through, Isolated) |
| Signal Type |
Analog |
| Voltage Range |
0–132 VAC/DC |
| Terminals per Input |
3 or 4 |
| Terminal Style |
Fixed Terminal Block |
| Mounting Type |
DIN Rail |
| Isolation |
Yes (per channel) |
| Weight |
0.14 kgs |
Information About 1492-AIFM6S-3
The 1492-AIFM6S-3 is part of the Allen-Bradley analog interface family and supports 0-132 VAC/DC analog signals, delivering robust performance in electrically noisy environments. It uses a fixed terminal block design with 3 to 4 terminals per input, streamlining field wiring while maintaining secure and segregated channel routing.
Key Features:
-
6 Independent Analog Channels: Allows simultaneous processing of six analog inputs with full electrical isolation.
-
Feed-Through Design: Simplifies connection between field devices and control systems with minimal signal loss.
-
Voltage Support: Compatible with analog signals in the 0–132 VAC/DC range.
-
Fixed Terminal Block: Offers 3 to 4 terminals per channel for easy and secure wiring.
-
High Signal Integrity: Isolation helps protect the control system from voltage surges and interference.
The 1492-AIFM6S-3 ensures signal reliability and electrical safety, making it a dependable solution for analog integration in demanding automation environments.
