Description

The Allen-Bradley 1489-M1D100 is a UL489-rated miniature circuit breaker engineered for compact and dependable branch circuit protection. It delivers 10 Amp D-curve tripping characteristics with a single-pole configuration and high interrupting capacity.

Technical Specifications

Information About 1489-M1D100

The 1489-M1D100 is part of the Allen-Bradley 1489-M series of miniature circuit breakers designed for branch circuit protection in control panels and electrical systems. This standard configuration breaker is rated up to 480Y/277V AC, offering versatility for use in a range of industrial and commercial environments. With its D-curve trip type, it is well-suited for inductive loads such as motors and transformers, offering delayed tripping under short-term inrush conditions. Certified under major global standards including UL, CUL, CE, CCC, CSA, and C-TICK, this breaker ensures compliance with safety regulations worldwide.

Key Features:

• Amperage / Current: 10 A current rating ensures consistent performance for general-purpose circuit protection.
• Interrupt Rating: High interrupt capacity of 15 kAIC allows safe operation under fault conditions.
• Number of Poles: Single-pole configuration is ideal for branch circuits requiring compact protection.
• Standard Compliance: Certified by UL, CUL, CE, CCC, CSA, and C-TICK for international acceptability.
• Trip Type: D-curve tripping provides delayed response for high inrush current applications.
• Type: Designed as a branch circuit protector for low-voltage distribution systems.
• Voltage: Operates at a maximum of 480Y/277 VAC for versatility in commercial and industrial systems.

The 1489-M1D100 offers compact, high-performance protection tailored for branch circuit loads, including inductive devices.
