12-Position Mini Aluminum Fusion Splice Tray (4" × 4")

This 12-position mini splice tray is a compact, lightweight solution for managing fusion splices in space-constrained fiber enclosures. Its small footprint makes it ideal for tight installations while still providing proper fiber routing, protection, and long-term reliability.

Preconfigured for standard heat-shrink fusion splices, the tray features a PSA-backed splice chip to securely hold splices in place. Integrated tie-down holes and a snap-on protective lid help maintain clean fiber management during installation and ongoing service. The aluminum construction offers durability without unnecessary weight, making this tray suitable for both new builds and retrofit applications.

Download product spec sheet (PDF)

Specifications

• Splice Capacity:

  • 12 fusion splices

• Splice Holding Method:

  • PSA-backed splice chip

• Material:

  • Black, powder-coated aluminum

  • .032" thickness

• Cover:

  • Snap-on protective lid

• Cable Management:

  • Tie-down holes for secure fiber routing

  • Mounting hole for fastening with stud and nut

• Dimensions (L × W × H):

  • 4" × 4" × 0.42"

• Compatibility:

  • Fits most standard fiber optic enclosures

• Included Accessories:

  • 12-position fusion splice chip

  • Zip ties

  • Tray label

  • Adhesive Velcro dots

This mini splice tray provides a clean, efficient fusion splice management option where space is limited, without sacrificing durability or fiber protection.
