Description

The Cisco 10GBASE-SR SFP+ transceiver (model SFP-10G-SR) is a hot-swappable optical module designed for short-range 10 Gigabit Ethernet applications over multimode fiber (MMF). It provides high-speed connectivity for data centers, enterprise wiring closets, and service provider transport networks.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Cisco
Category	Networking Equipment
Part Number	10GBASE-SR
Subcategory	SFP+ Modules
Network Technology	10GBase-SR
Media Type Supported	Optical Fiber
Interfaces/Ports Details	(1) LC Duplex 10GBase-SR Network
Total Number of Ports	1
Compatibility	MSA Compliant Cisco Firepower Switches: ASR9000, C9300, C3850, C9500
Connector Type	LC
Ethernet Technology	10 Gigabit Ethernet
Environmentally Friendly	Yes
Fiber Mode Supported	Multi-mode
Item	SFP+
Depth	2.3 in
Height	0.5 in
Width	0.5 in
Wavelength	850 nm
Data Rate	11.1 Gb/s
Power Consumption	1 W
Max Distance	OM3: 300 m (984 ft)
Temperature Range	Industrial Temp: -40°C to 85°C
Weight	0.22 kgs





Information About 10GBASE-SR

The Cisco 10GBASE-SR SFP+ transceiver (model SFP-10G-SR) is a short-reach, hot-swappable optical module designed for 10 Gigabit Ethernet applications over multimode fiber. It provides high-speed, energy-efficient connectivity for data centers, enterprise wiring closets, and service provider networks.

Key Features:

• Transceiver Type: 10GBASE-SR SFP+

• Interface: SFP+ (Small Form-Factor Pluggable Plus)

• Wavelength: 850 nm

• Connector Type: LC duplex

• Maximum Data Rate: 10.3 Gbps

• Fiber Type: Multimode Fiber (MMF)

• Transmission Distance:

  • 26 m on OM1

  • 300 m on OM3

  • 400 m on OM4

• Digital Optical Monitoring (DOM): Supported

• Power Consumption: < 1.0 W

• Hot-Swappable: Yes

• Operating Temperature Range: 0°C to 70°C (32°F to 158°F)

This transceiver is ideal for high-density, short-reach 10G Ethernet deployments, offering a compact, cost-effective solution for high-bandwidth network connections.
