Description
The 1079651 H-distributor from Phoenix Contact’s PRC 35 series is a pre‑assembled power distributor designed for efficient energy routing in industrial, photovoltaic, and automation applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
General Electric |
| Category |
|
| Part Number |
1079651 |
| Subcategory |
Connector/Terminal/Pin |
| Product Family |
PRC 35 |
| Coding |
AD |
| Halogen-Free |
Yes |
| Nominal Voltage |
400 V (III/2.00) |
| Rated Surge Voltage |
8 kV (III/2) |
| Rated Current |
32 A (observe derating curve) |
| Protection Class |
II |
| Degree of Pollution |
2 |
| Insertion/Withdrawal Cycles |
2000 |
| Insertion Force |
70 N ±10 N |
| Housing |
Polycarbonate (Black, RAL 9005)
|
Contact Carrier
|
PPE |
| Contact Material |
CuZn (Lead content < 0.1%) |
| Contact Surface |
Sn (Tin-plated) |
| Seal Material |
TPE |
| O-ring Material |
Silicon |
| Locking Screw |
Fiber-reinforced Polycarbonate |
| Flammability Rating (UL94) |
V0 |
| Degree of Protection |
IP66 / IP67 / IP69 |
| Operating Temperature |
–40 °C to +70 °C (derating applies) |
| Storage/Transport Temperature |
–40 °C to +70 °C |
| Assembly Temperature |
–5 °C to +85 °C |
| Width |
238 mm |
| Height |
129 mm |
| Length |
77 mm |
| Weight |
0.691 kgs |
| Replacement Number |
4416 |
Information About 1079651
The 1079651 is part of Phoenix Contact’s PRC 35 family of pre-assembled power distribution systems, engineered for robust and flexible energy branching in industrial, photovoltaic, and automation environments. This H-distributor features one input and three output ports (1I3/3O3), supporting nominal voltages up to 400 V and rated currents up to 32 A, making it ideal for medium-load distribution tasks. Designed with a rugged housing and IP66/IP67/IP69 protection, it offers plug-and-play installation with a locking system that can be released manually or with a tool. Its compact 238 × 129 × 77 mm design ensures durable integration in both indoor and outdoor systems.
Key Features:
- Pre-Assembled H-Distributor: Ready-to-use power distribution module with 1 input and 3 output connectors for fast and error-free field deployment.
- High Voltage and Current Ratings: Supports up to 400 V (III/2) and 32 A with an 8 kV surge voltage rating, suitable for power-hungry loads.
- Rugged Polycarbonate Housing: Made of UL 94 V0 flame-retardant materials with black (RAL 9005) finish and silicon/TPE seals for long-term reliability.
- Superior Environmental Protection: IP66/IP67/IP69 ingress protection allows use in demanding outdoor and washdown environments.
- Quick-Connect Design: Plug-and-play setup with 2000 insertion cycles and 70 N mating force ensures efficient operation and longevity.
- Galvanic Isolation and Safety: Insulated to Protection Class II with 1500 V electrical isolation and meets overvoltage category III requirements.
- Wide Operating Temperature Range: Operates reliably between –40 °C and +70 °C, and installs at temperatures up to 85 °C.
- Halogen-Free and Flame-Retardant: Built for environmentally friendly performance with halogen-free construction and V0 flammability rating.
The 1079651 H-distributor combines high current capacity, robust environmental resistance, and ease of installation for power distribution in industrial and energy applications. With its pre-configured wiring and certified design, it’s a practical solution for decentralized power management in harsh conditions.
