Description
The Allen-Bradley 100-C43EJ10 is a 43 A IEC contactor featuring 3 normally open (3NO) main contacts and 1 normally open (1NO) auxiliary contact, with a 24V DC electronic coil.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
Contactors & Starters
|
| Part Number |
100-C43EJ10 |
| Subcatecory |
|
|
|
43 Amp at 400 VAC-3, 85 Amp at 400 VAC-1 |
Connection Type
|
Screw-Type Terminals |
| Power Rating |
22 kW |
| Voltage |
230-690 VAC at 50 Hz, 115-575 VAC at 60 Hz |
| Coil Voltage |
24 V |
| Contact Configuration |
1 NO Auxiliary |
| Number of Poles |
3 Pole |
| Standard |
C-TICK,CCC |
| Weight |
1.15 lbs |
Information About 100-C43EJ10
The Allen-Bradley 100-C43EJ10 is a compact IEC contactor engineered for efficient and reliable motor control in industrial automation systems. Part of the 100-C series, it is ideal for applications where space-saving design and dependable performance are essential. This model is equipped with an energy-saving 24V DC electronic coil and includes an integrated 1 normally open (1NO) auxiliary contact.
Key Features:
- Type: IEC Motor Contactor
- Series: Allen-Bradley Bulletin 100-C Series
- Rated Current (AC-3): 43 A @ 400V
- Motor Rating: Up to 22 kW (30 HP) @ 400/415V
- Number of Poles: 3 (3 Normally Open contacts)
- Auxiliary Contacts: 1 NO included
- Coil Voltage: 24V DC (electronic coil with surge suppression)
- Control Circuit Type: DC-operated, electronic
- Mechanical Life: Up to 10 million operations
- Electrical Life: Up to 1 million operations (AC-3 duty)
- Mounting Options: DIN rail or panel mount
- Terminal Type: Screw terminals
- Housing Material: Industrial-grade thermoplastic
- Ingress Protection: IP20 (when enclosed in cabinet)
- Standards Compliance: CE, UL, CSA, CCC
- Operating Temperature Range: -25 °C to +60 °C (-13 °F to +140 °F)
The Allen-Bradley 100-C43EJ10 offers a powerful combination of energy-efficient coil technology and durable performance in a compact footprint. With integrated auxiliary contact and global certifications, it supports flexible, standards-compliant motor control in modern industrial systems.
