[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 6 (802.11ax) and 4x PoE+ ports, powered by SP5 ASIC, delivering up to 10 Gbps firewall throughput and including a 3-Year Unified Threat Protection bundle[/shortdesc]
[properties]
| SKU |
FWF-70G-POE-A-BDL-950-36 |
| Form Factor |
Desktop |
| Wireless Standard |
802.11 a/b/g/n/ac/ax (Wi-Fi 6) |
| PoE Interfaces |
4x GE RJ45 PoE/+ Ports |
| Firewall Throughput |
10 Gbps |
| Interfaces |
2x GE WAN, 4x GE Internal, 4x GE PoE/+, 1x USB, 1x Console |
| Dimensions (H x W x L) |
40.5 x 216 x 160 mm (1.6 x 8.5 x 6.3 inches) |
| Weight |
1.07 kg (2.36 lbs) |
| Power Input |
54V DC (External Adapter) |
| Bundle Included |
3 Year Unified Threat Protection (IPS, AMP, Web Filtering, Anti-Spam) |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) |
| IPS Throughput |
2.5 Gbps |
| NGFW Throughput |
1.5 Gbps |
| Threat Protection Throughput |
1.3 Gbps |
| System Performance & Capacity |
| IPv4 Firewall Throughput |
10 Gbps (1518/512/64 byte UDP) |
| Firewall Latency |
2.46 μs |
| Concurrent Sessions (TCP) |
1.4 Million |
| New Sessions/Second (TCP) |
100,000 |
| Firewall Policies |
5,000 |
| IPsec VPN Throughput |
7.1 Gbps |
| SSL Inspection Throughput |
1.4 Gbps |
| Wireless Specifications |
| Radio |
Dual Radio (2.4 GHz / 5 GHz) |
| Antenna Ports |
3x SMA (External) |
| Hardware Specifications |
| USB Port |
1x USB Port |
| Console Port |
1x RJ45 Console Port |
| Total Available PoE Power Budget |
60 W |
| Environment & Power |
| Power Consumption (Avg / Max) |
74.9 W / 77.7 W |
| Heat Dissipation |
264.96 BTU/hr |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
10% to 90% non-condensing |
| Noise Level |
17.75 dBA |
| Certifications |
| Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications |
USGv6/IPv6 |
[/specifications]
[accesories]
| Optional Accessories |
Rack Mount Tray (SP-RACKTRAY-02), Mounting Ear Bracket (SP-EAR-FG90G-10), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG50G-POE-PDC-5) |
[/accesories]
Integrated PoE+ and Wi-Fi 6 Security with Unified Threat Protection
The FortiWiFi 70G-POE (FWF-70G-POE-A-BDL-950-36) is a converged security solution designed to simplify branch office infrastructure. This 3-Year Unified Threat Protection (UTP) bundle provides essential defense against web-based attacks, malware, and intrusions. Powered by the Fortinet SP5 ASIC, it combines 10 Gbps firewall throughput, integrated Wi-Fi 6, and 4x PoE+ ports to power downstream devices like cameras and IP phones.
This all-in-one appliance reduces the need for separate switches and power injectors, lowering total cost of ownership. With its integrated dual-band Wi-Fi 6 radio and Secure SD-WAN capabilities, the FWF-70G-POE ensures secure, high-performance connectivity for both wired and wireless users.
Key Benefits
-
3-Year Unified Threat Protection: Includes industry-leading security services: IPS, Advanced Malware Protection, URL Filtering, and Anti-Spam.
-
Integrated PoE+ Ports: Features 4x GE RJ45 PoE/+ ports with a 60W budget to power IP phones, cameras, or access points directly.
-
Powered by SP5 ASIC: Delivers industry-leading performance with 10 Gbps firewall throughput and 7.1 Gbps IPsec VPN throughput.
-
Integrated Wi-Fi 6: Built-in dual-band 802.11ax access point provides secure, high-speed wireless coverage.
-
Unified Management: Consolidates security, Wi-Fi, switching, and PoE power management into a single FortiOS console.
-
Secure SD-WAN: Integrated SD-WAN capabilities ensure optimal application performance and secure direct internet access.
Ideal Use Cases
-
Retail Branches: Powers POS systems and cameras while securing Wi-Fi and SD-WAN connectivity with enterprise-grade protection.
-
Small Offices: All-in-one networking solution that eliminates the need for separate switches, access points, and power injectors.
-
Distributed Enterprises: Scalable, secure connectivity with centralized management for remote locations.
Technical Specifications Summary
-
Firewall Throughput: 10 Gbps (1518/512/64 byte UDP)
-
IPS Throughput: 2.5 Gbps (Enterprise Traffic Mix)
-
NGFW Throughput: 1.5 Gbps (Enterprise Traffic Mix)
-
Threat Protection Throughput: 1.3 Gbps (Enterprise Traffic Mix)
-
IPsec VPN Throughput: 7.1 Gbps (512 byte)
-
SSL Inspection Throughput: 1.4 Gbps (IPS, avg. HTTPS)
-
Concurrent Sessions (TCP): 1.4 Million
-
Interfaces: 10x GE RJ45 Ports (4x PoE/+, 4x Internal, 2x WAN) + 1x USB + 1x RJ45 Console
-
Wireless: Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax (Wi-Fi 6), 3x SMA antenna ports
-
Total PoE Budget: 60 W (max 30 W per PoE/+ port, 802.3at)
-
Power Consumption (Avg / Max): 74.9 W / 77.7 W
-
Dimensions / Weight: 40.5 x 216 x 160 mm; 1.07 kg
Upgrade Your Network Security
Simplify your branch deployment with the FortiWiFi 70G-POE and 3-Year Unified Threat Protection bundle.
