[shortdesc] Firewall, SFP uplink, 4x PoE+ GE ports, Secure SD-WAN ASIC SP5, 60W PoE budget, including 1 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]
[properties]
| Feature | Details |
| Product SKU | FG-50G-SFP-POE-BDL-950-12 |
| Base Model | FG-50G-SFP-POE |
| Bundle Contents | Firewall plus FortiCare Premium and FortiGuard Unified Threat Protection (UTP) (1 Year Contract) |
| Form Factor | Desktop |
| Firewall Throughput | 5 / 5 / 4 Gbps (1518/512/64 byte UDP packets) |
| Interfaces | 3x RJ45 PoE+ ports, 1x RJ45 PoE+ WAN, 1x RJ45 WAN port, 1x SFP port |
| PoE Budget | 60 W |
| Threat Protection | 1.1 Gbps |
| Power Input | 54VDC |
| Dimensions (H x W x L) | 1.6 x 8.5 x 6.3 inches (40.5 x 216 x 160 mm) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Compliance / Certifications | FCC, ISED, CE, UL/cUL, CB, USGv6/IPv6 |
[/properties]
[specifications]
| System Performance & Capacity |
| IPS Throughput | 2.25 Gbps |
| NGFW Throughput | 1.25 Gbps |
| Firewall Latency | 2.42 μs |
| Concurrent Sessions (TCP) | 720,000 |
| New Sessions/Second (TCP) | 85,000 |
| Firewall Policies | 2,000 |
| VPN Performance |
| IPsec VPN Throughput (512 byte) | 4.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL Inspection Throughput | 1.3 Gbps |
| Hardware & Environment |
| USB Port | 1x USB |
| Console Port | 1x RJ45 |
| Power Consumption (Average / Max) | 75.4 W / 76.3 W |
| Heat Dissipation | 260.48 BTU/h |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Noise Level | Fanless, 0 dBA |
[/specifications]
[accesories]
| Accessory Type | Description |
| Optional | Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG50G-POE-PDC-5P), Power cable (SP-FGPCOR-XX) sold separately |
[/accesories]
The FortiGate 50G-SFP-POE series simplifies SD-Branch architecture by integrating advanced security, SD-WAN, and power delivery into a single compact appliance. Built on the Fortinet Secure SD-WAN ASIC SP5, this appliance delivers high-speed inspection while providing integrated PoE+ capabilities to support essential downstream devices such as wireless access points and IP phones directly from the firewall. This bundle includes FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for a 1-year contract term.
Designed for flexibility and reduced footprint, the FG-50G-SFP-POE features a fanless desktop form factor ideal for noise-sensitive environments. It includes a dedicated SFP port for fiber uplinks and multiple PoE+ capable RJ45 ports (including a PoE+ WAN port and FortiLink), allowing for diverse connectivity options and streamlined deployment in retail stores, small offices, and distributed enterprise sites.
Converged Security with Integrated PoE+ Power
Key Benefits
-
Integrated Power over Ethernet: Powers compatible devices over PoE+ to reduce the need for separate injectors and simplify installations.
-
SP5 ASIC Acceleration: Built on Fortinet’s Secure SD-WAN ASIC SP5 to enhance performance for security and SD-WAN use cases.
-
Fiber & Copper Connectivity: Supports fiber uplinks via SFP alongside RJ45 WAN/LAN connectivity for flexible deployments.
-
Unified Management: Centralizes control of networking, security, and connected devices through the FortiOS operating system.
-
Silent Operation: Fanless design supports quiet desktop or open-office deployments.
-
Bundle Coverage Included: FortiCare Premium and FortiGuard Unified Threat Protection (UTP) (1-year contract) included with the firewall.
Ideal Use Cases
-
SD-Branch Deployment: Powers and secures branch infrastructure like Wi-Fi APs and VoIP phones with a single consolidated device.
-
Retail Point of Sale: Secures transaction data while powering surveillance cameras or IP-connected retail devices.
-
Small Office Connectivity: Provides fiber uplink capability (SFP) and local wired connectivity with enterprise-grade protection.
-
Remote Work: Delivers secure, high-performance VPN access for remote employees with simplified infrastructure requirements.
Technical Specifications Summary
-
Firewall throughput (1518/512/64 byte UDP): 5 / 5 / 4 Gbps.
-
IPS throughput (Enterprise Mix): 2.25 Gbps.
-
NGFW throughput: 1.25 Gbps.
-
Threat protection throughput: 1.1 Gbps.
-
IPsec VPN throughput (512 byte): 4.5 Gbps.
-
SSL inspection throughput (IPS, avg. HTTPS): 1.3 Gbps.
-
Firewall latency (64 byte UDP): 2.42 μs.
-
Sessions capacity: 720,000 concurrent sessions (TCP), 85,000 new sessions/second (TCP).
-
PoE power budget: 60 W total available PoE power (max 30 W per PoE/+ port).
-
Power and thermals: 54VDC input, 75.4 W / 76.3 W power consumption (avg/max), 260.48 BTU/h heat dissipation.
-
Physical: 1.6 x 8.5 x 6.3 in (40.5 x 216 x 160 mm), desktop form factor.
-
Environment: 32°F to 104°F (0°C to 40°C) operating, fanless 0 dBA.
Upgrade Your Network Security
Deploy the FortiGate 50G-SFP-POE Bundle (FG-50G-SFP-POE-BDL-950-12) today for a streamlined, powerful, and PoE-capable firewall, including FortiCare Premium and FortiGuard Unified Threat Protection (UTP) coverage for 1 year.
